User Manual
P-660HN-TxA
802.11n Wireless ADSL2+ 4-port
Gateway
Firmware v3.40
Edition 1, 6/2010
DEFAULT LOGIN DETAILS
IP Address:
Password:
www.zyxel.com
http://192.168.1.1
1234
Copyright 2010
ZyXEL Communications Corporation
Advertisement
Related Manuals for ZyXEL Communications P-660HN-TxA
Summary of Contents for ZyXEL Communications P-660HN-TxA
- Page 1 P-660HN-TxA 802.11n Wireless ADSL2+ 4-port Gateway Firmware v3.40 Edition 1, 6/2010 DEFAULT LOGIN DETAILS IP Address: http://192.168.1.1 Password: www.zyxel.com 1234 Copyright 2010 ZyXEL Communications Corporation...
- Page 2 Device Panels WPS/WLAN BUTTON POWER LAN1-4 DSL PORT WPS/WLAN INTERNET LAN PORT 1-4 RESET POWER ON/OFF...
-
Page 3: Hardware Connections
P-660HN-TxA Overview The P-660HN-TxA is an ADSL router with a four-port built-in Ethernet switch and IEEE 802.11n wireless capability. The P-660HN-TxA allows wired and wireless clients to safely access the Internet. Hardware Connections This section shows you how to set up your P-660HN-TxA. - Page 4 1. DSL: Use a telephone wire to connect your P-660HN-TxA’s DSL port to a telephone jack (or to a splitter, if one is already installed). 2. LAN: Use an Ethernet cable to connect a computer to a LAN port for initial configuration and/or Internet access.
- Page 5 P-660HN-TxA Internet and Wireless Setup 1. In your browser, go to http://192.168.1.1. 2. Enter the default password 1234 and click Login. 3. Select Go to Advanced Setup then click Apply.
- Page 6 4. The Status screen displays. Open the Network > Wireless LAN > AP screen. 5. Select Enable Wireless LAN, then select the country in which your P-660HN-TxA operates.
- Page 7 P-660HN-TxA to finish detection. If any other screens appear, follow the directions in the screen. If the web page opens correctly, your P-660HN-TxA is ready for you to use. Skip the rest of this procedure. If the web page does not open, follow the rest of the steps. You should have the information provided by your ISP.
-
Page 8: Troubleshooting
2. If you cannot access the Internet when your computer is connected to the LAN port, follow these steps. a. Check the lights on the front panel. If they are different from what is described on page 4, make sure the P-660HN-TxA is correctly... - Page 9 On a computer in the wireless network, open your browser, and go to http://192.168.1.1. If you see the login screen, follow suggestions b. Make sure your P-660HN-TxA and your computer are using the same wireless and wireless security settings. Viewing Certification(s) •...
