Gigabyte G-MAX TA3 User Manual

Ta series thin client pc
Hide thumbs Also See for G-MAX TA3:
Table of Contents

Advertisement

Quick Links

1
CONTENTS
Certificate of Test ........................................................................................ 2
FCC Compliance Statement ..................................................................... 4
Introduction ................................................................................................. 5
Features ........................................................................................................ 5
Chapter One Getting started
1.1 Items in the Package ............................................................................6
1.2 Front and Rear Panel Components .....................................................7
Chapter Two Installation
2.1 Upload Case ..........................................................................................8
2.2 Installing Memory ...................................................................................9
2.3 Installing DOM (DISK On Module) .........................................................10
Appendix A Specification ...........................................................................11

Advertisement

Table of Contents
loading

Related Manuals for Gigabyte G-MAX TA3

Summary of Contents for Gigabyte G-MAX TA3

  • Page 1: Table Of Contents

    CONTENTS Certificate of Test ..................2 FCC Compliance Statement ..............4 Introduction ....................5 Features ......................5 Chapter One Getting started 1.1 Items in the Package ................6 1.2 Front and Rear Panel Components .............7 Chapter Two Installation 2.1 Upload Case ..................8 2.2 Installing Memory ...................9 2.3 Installing DOM (DISK On Module) ............10 Appendix A Specification ................11...

  • Page 4: Fcc Compliance Statement

    FCC COMPLIANCE STATEMENT For Users in the USA This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of FCC Rules. These rules are designed to provide reasonable protection against harmful interference when the equipment is operated in a residential installation.

  • Page 5: Introduction

    • Please turn the power off before connecting or assembling any peripheral. May/2005 Features TA series has been equipped with the motherboards developed by Gigabyte Technology to ensure the best performance under Windows / Linux environment for thin client applications.

  • Page 6: Items In The Package

    1.1 Items in the Package Driver CD keyboard (option) mouse (option) Power Cord TA Series...

  • Page 7: Front And Rear Panel Components

    1. Front and Rear Panel Component Power Button Power Indicator LAN Indicator HDD Indicator MIC Jack Earphone Jack PCMCIA Port (Not Support) USB Port PCMCIA Enject Button (Not Support) Mouse(PS2) Keyboard (PS2) USB Port VGA Port Paralle Port Serial Port 1 Audio Out Audio In Serial Port 2...

  • Page 8: Upload Case

    2.1 Upload Case Materials of the case has been tested to comply with the UL specification and designed for space and screw saving purposes. Users simply need to remove one screw from the back to unload the case cover and access to the inside of the case.

  • Page 9: Installing Memory

    2.2 Installing Memory Clicks at side of the RAM module SDRAM Align the fool-proof clicks on the bottom of the RAM module to the socket, and the locks on the socket should securely lock on the clicks at sides of the module as shown in the above picture.

  • Page 10: Installing Dom (Disk On Module)

    2.3 Installing DOM (DISK On Module) Step 1: Install DOM on the DOM slot (J1). Attention! TA3 Series are device-less (NO HDD & ODD).

  • Page 11: Appendix A Specification

    PC case With side cover: 70(W)mm x 236(H)mm x 213(D)mm Processor VIA C3 800 MHz for TA3 V.B1 VIA Eden6000 667MHz for TA3 V.B2 (Fan-less model) VIA C3 1GHz for TA3 V.B3 Chipset VIA CLE 266 VIA VT8235 Chipset with Built-in enhanced Graphics AC97 Audio Codec-Realtek ALC655 LAN Controller-Realtek RTL8100C DRAM...
  • Page 12 VIA Eden6000 667MHz forTA3 V.B2 VIA C3 800 MHz for TA3 V.B1 VIA C3 1GHz for TA3 V.B3 Specification of hardware is subject to change without notice. Please visit out site at http://www.gigabyte.com.tw/ to download the latest version of drivers.
  • Page 13 MEMO...
  • Page 14 MEMO...
  • Page 15 MEMO...
  • Page 16 MEMO...
