Here,
a list of bit fields. Each component identifer requires a colon and its width in bits
to be explicitly specified. Total width of all components cannot exceed one byte (8
bits).
As an object, bit fields structure takes one byte. Individual fields are packed with-
in byte from right to left. In
fier(s) to create artificial "padding", thus skipping irrelevant bits.
For example, if we need to manipulate only bits 2–4 of a register as one block, we
could create a structure:
struct {
unsigned
mybits
} myreg;
Here is an example:
typedef struct {
prescaler
which declares structured type
prescaler
and 6).
Bit Fields Access
Bit fields can be accessed in same way as the structure members. Use direct and
indirect member selector (
previously declared
// Declare a bit field TimerControl:
mybitfield TimerControl;
void main() {
TimerControl.prescaler
TimerControl.timeronoff = 1;
TimerControl.postscaler = 3;
T2CON = TimerControl;
}
