  • Page 1: Table Of Contents

    Table of Contents TABLE OF CONTENTS INTRODUCTION 1.1. PREFACE ...................... 1-1 1.2. KEY FEATHERS.................... 1-1 1.3. PERFORMANCE LIST .................. 1-2 1.4. BLOCK DIAGRAM..................1-3 1.5. INTRODUCE THE PENTIUM II/ III PROCESSORS ......... 1-4 1.6. WHAT IS AGP ....................1-5 SPECIFICATION 2.1.
  • Page 2 6ZXC 3.11. PERIPHERAL DEVICE INSTALLATION ............ 3-8 3.12. KEYBOARD & PS/2 MOUSE INSTALLATION........... 3-8 BIOS CONFIGURATION 4.1. ENTERING SETUP ..................4-1 4.2. CONTROL KEYS................... 4-1 4.3. GETTING HELP..................... 4-2 4.3.1. Main Menu ..................4-2 4.3.2. Status Page Setup Menu / Option Page Setup Menu....... 4-2 4.4.
  • Page 3: Introduction

    Introduction INTRODUCTION 1.1. PREFACE Welcome to use the 6ZXC motherboard. It is a Pentium II / III / Celeron Processor based PC / AT compatible system with AGP / PCI / ISA Bus, and has been designed to be the fastest PC / AT system. There are some new features allow you to operate the system with just the performance you want.
  • Page 4: Performance List

    6ZXC 1.3. PERFORMANCE LIST The following performance data list is the testing results of some popular benchmark testing programs. These data are just referred by users, and there is no responsibility for different testing data values gotten by users. (Different Hardware & Software configuration will result in different benchmark testing results.)
  • Page 5: Block Diagram

    Introduction 1.4. BLOCK DIAGRAM 14.318MHz SLOT 1 3.3V SDRAM DIMM Sockets Host Bus 66 / 66 / 100 MHz 100 MHz INTEL 33MHz 82443ZX AGP Bus 66 / CHIPSET 66MHz 100 MHz 9148-26 24 MHz 33 MHz Ultra DMA/33 IDE Ports PCI Bus 33 MHz PIIX4...
  • Page 6: Introduce The Pentium Ii/ Iii Processors

    6ZXC 1.5. INTRODUCE THE Pentium II / III Processors Figure 1: Universal Retention Mechanism & attach Mount Figure 2:OEM Pentium II Processor...
  • Page 7: What Is Agp

    Introduction Figure 3: OEM Pentium III Processor 1.6 What is AGP The Accelerated Graphics Port (AGP) is a new port on the Host-To-PCI bridge device that supports an AGP port. The main purpose of the AGP port is to provide fast access to system memory. The AGP port can be used either as fast PCI port (32-bits at 66MHz vs.32-Bits at 33MHz) or as an AGP port which supports 2x data-rate, a read queue, and side band addressing.
  • Page 9: Specification

    6ZXC SPECIFICATION 2.1. HARDWARE Pentium II / III/ Celeron processor 333 – 650MHz. 242 pins 66 / 100MHz slot1 on board. 66/100 MHz system speed. SPEED 66 MHz AGP bus speed. (2X mode 133MHz) 33 MHz PCI-Bus speed. 8 MHz AT bus speed.
  • Page 10: Software

    Specification Suspend mode support. GREEN FUNCTION Green switch & ACPI LED support. IDE & Display power down support. Monitor all IRQ / DMA / Display / I/O events. 2M bits FLASH RAM. BIOS Supports Plug & Play, DMI Function. ATX Form Factor, 4 layers PCB. DIMENSION 2.2.
  • Page 11: Hardware Installation

    6ZXC HARDWARE INSTALLATION 3.1. UNPACKING The main board package should contain the following: The 6ZXC main board. The Universal Retention Mechanism & Attach Mount USER’ S MANUAL for main board. Cable set for IDE, Floppy devices. Diskettes for main board Utility.
  • Page 12: Mainboard Layout

    Hardware Installation 3.2. MAINBOARD LAYOUT COM A COM B PS/2 SLOT5 SLOT3 SLOT1 BIOS PCI 4 PCI 3 PCI 2 PCI 1 JP10 CPU FAN JP13 Intel JP12 440ZX SW 1 PWR FAN PIIX4 BAT1 BANK 1 BANK 0 SLOT6 SLOT4 SLOT2 IDE 2...
  • Page 13 6ZXC CPU FAN : CPU cooling FAN Power Connector Pin No. Function GND. +12V SENSE Power FAN : Power FAN Power Connector Pin No. Function GND. +12V SENSE System FAN : System FAN Power Connector Pin No. Function GND. +12V...
  • Page 14 Hardware Installation JP11 : CLEAR CMOS Function Pin No. Function 1-2 short CLEAR CMOS Function 2-3 short Normal Operation.(Default) Internal Ring Power on Pin No. Function +5VSB JP8 SB-LINK : For PCI Sound Card Connector Pin No. Function Signal Signal Signal IR: INFRARED Connector (OPTIONAL) Pin No.
  • Page 15 6ZXC PWR: Soft Power Connector Open: Normal Operation Short: Power On/Off RES: Reset Switch Open: Normal Operation Short: For Hardware Reset System P+P P : Power LED PIN 1 : anode (+) PIN 2 : cathode ( ) PIN 3 : cathode ( )
  • Page 16: Dram Installation

    Hardware Installation 3.4. DRAM INSTALLATION The main board can be installed with 8 / 16 / 32 / 64 / 128 / 256 MB 168 pins DIMM module DRAM, and the DRAM speed must be 67~100 MHz for SDRAM when system bus speed is set to 66MHz. When system bus speed is set to 100MHz, 100MHz SDRAM is required.
  • Page 17: Cmos Rtc & Isa Cfg Cmos Ram

    6ZXC Pentium II/III 550 MHz Pentium II/III 600 MHz Pentium II/III 650 MHz The CPU is a sensitive electric component and it can be easily damaged by static electricity, so users must keep it away from metal surface when the CPU is installed onto main board.
  • Page 18: Ide & Atapi Device Installation

    Hardware Installation 3.10. IDE & ATAPI DEVICE INSTALLATION There are two-Enhanced PCI IDE ports (IDE1, IDE2) on board, which following ATAPI standard SPEC. Any one IDE port can connected to two ATAPI devices (IDE Hard Disk, CD-ROM & Tape Driver), so total four ATAPI devices can exist in a system.
