  • Page 1 Automatic Washers Metered Commercial TLW12C TLW12C Keep These Instructions for Future Reference. (If this machine changes ownership, this manual must accompany machine.) Part No. 202068R2 www.comlaundry.com February 2009...
  • Page 3 W022 IMPORTANT: Read the complete INSTALLATION/OPERATION INSTRUCTIONS before using the washer. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 202068...

  • Page 4: Table Of Contents

    All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any means without the expressed written consent of the publisher. 202068 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 5: Safety Information

    8. Do not reach into the washer if the washtub or agitator is moving. 9. Do not install or store the washer where it will be exposed to water and/or weather. 202068 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 6 20. Be sure water connections have a shut-off valve and that fill hose connections are tight. CLOSE the shut-off valves at the end of each wash day. 202068 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 7: Installation

    Dimensions and Specifications 22.44 in. (57 cm) 0.44 in. 26 in. (66.04 cm) 25.63 in. (65.1 cm) (1.12 cm) 28 in. (71.12 cm) TLW2097N Pilot Hole TLW2097N 202068 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 8: Before You Start

    IMPORTANT: Install dryer before washer. This allows room for attaching exhaust duct. TLW2 TLW2098N Shipping Brace Shipping Plug Cardboard Base Figure 2 202068 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 9: Step 2: Wipe Out Inside Of Washtub

    This will release any accumulated hydrogen gas. The gas is flammable, do not smoke or use an open flame during this time. W029 202068 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 10: Connecting Hoses

    All hoses should be checked on a monthly basis for any visible signs of deterioration. Any hose showing the signs of deterioration listed above should be replaced immediately. All hoses should be replaced every five years. 202068 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 11: Step 4: Connect Drain Hose To Drain Receptacle

    Remove the drain hose from its shipping position on the rear of the washer by unhooking the hose from the retainer clamp. 202068 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 12: Step 5: Position And Level The Washer

    Place rubber cups on all four leveling legs. Place a level on the cabinet top and check if the washer is level from side to side and front to back. 202068 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 13: Step 6: Plug In The Washer

    110/120 Volts AC (alternating current) 15 Amps. Refer to Figure 10 to determine correct polarity of the wall receptacle. 202068 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 14: Step 7: Add Water To The Washer

    NOTE: The agitator should not be removed except for service. The washtub is designed to be self- cleaning. 202068 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 15: Vending

    2. Remove two screws holding control panel to control hood. FLW6R 3. Tilt control panel forward and lay on a protective Control Panel pad to prevent scratching of cabinet top. Figure 13 202068 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 16 7. Remove two screws holding front panel to base of washer and install two No. 12 tamper-resistant screws, Part No. 35527. TLW2102N 35528 No. 8 Screws Double “D” Hole 35527 No. 12 Screws Figure 14 202068 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 17: Operation

    If desired, fabric softener may be added to rinse water when RINSE light comes on. W392I Figure 16 Step 3: Close Lid Washer will not operate with lid open. W395I Figure 15 H338I Figure 17 202068 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 18: Step 4: Set Fabric Selector

    Step 7: Insert Money or Card To Insert Money Insert coin(s) in coin slot. Check pricing as seen on digital display. TLW2116N Figure 19 W387I Figure 21 202068 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 19: Step 8: Start Washer

    LID MUST BE CLOSED TO START WASHER. MEDIUM is lit if selected for the current cycle. HEAVY HEAVY is lit if selected for the current cycle. TLW2117N Figure 23 202068 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 20: Maintenance

    If the overload protector stops motor again, remove the Order filter screen Part No. F270300 from the nearest washer from use and call the service person to correct authorized parts distributor. the problem. 202068 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 21: Troubleshooting

    • Check the laundry room fuse or circuit breaker. • The motor overload protector may have stopped the cycle. It will reset itself in two or three minutes and restart the washer automatically. 202068 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 22 “H” on the valve bracket) and cold faucet is connected to cold mixing valve (indicated with “C” on the valve bracket). • Make sure laundry room water heater is adjusted properly. 202068 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 23: Contact Information

    (920) 748-3950 for the name and address of the nearest authorized parts distributor. TLW12C W138P TLW12C Nameplate Figure 25 202068 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 26: Installer Checklist

    Installer Checklist Fast Track for Installing the Washer (Refer to the manual for more detailed information) ➊ ➎ • Remove the • Position LEVEL Shipping Brace and Level D255I D255I and Shipping Plug. the Washer. W316IE0A W316IE0A CHECK CHECK TLW2098N TLW2098N ➏...
