American Standard Ellisse Elite 2711EC Specifications

ELLISSE ELITE™ 6' x 48" WHIRLPOOL
Comfortable two person design with generous
back support position and integral seat
2711E (specify White 020, Bone 021, or
Linen 222)
• Acrylic with fiberglass reinforcement
• 2.0 HP self-draining pump/motor
with dry run seal
• Six multi-directional and flow adjustable
jets including:
Three high performance Ideal-flow™ Jets
Three interchangeable Flex-jets™
• Two silent air volume controls
• Deck-mounted On/Off control
• Complete factory installed and tested
whirlpool system
2711EC (specify White 020, Bone 021, or
Linen 222)
• Same as above with the StayClean™
whirlpool system featuring Antimicrobial
AlphaSan®
Nominal Dimensions: 72" x 48" x 21-1/2"
(1829 x 1220 x 546mm)
Components Needed:
Bath Filler*: (specify finish)
Bath Drain: BATH-DRAIN
(specify Chrome 002, Polished Brass 099,
or Satin 295)
Custom Accessories Available:
Pulse Jet Kit: PULSE-JET (two per kit,
specify White 020, Bone 021, or Linen 222)
Soft Jet Kit: SOFT-JET (two per kit, specify
White 020, Bone 021, or Linen 222)
E-Z-Install™ Whirlpool Heater - EZHEAT-100
Tile Bead Kit: TILE-BEAD
* See American Standard Faucet Selector
Revised 6/03
WHIRLPOOLS BY AMERICAN STANDARD
Compliance Certifications -
Meets or Exceeds the Following Specifications:
• Underwriters Laboratories - Hydromassage
Bathtubs UL 1795
• ASME A112.19.7M for Whirlpool Appliances
• ANSI Z124.1 for Plastic Bathtubs
• ASTM E162 for Flammability
• NFPA 258 for Smoke Density
NOTE: Roughing-in dimensions and product specifica-
tions shown on reverse side of page.
NOTE: E-Z-Install™ Whirlpool Heater is designed to
maintain water temperature during operation. It will not
heat cold water to desired bathing temperature.
SPS 2711E
© 2003 American Standard Inc.
ELLISSE ELITE™ 6' x 48"
HIGH GLOSS ACRYLIC
HD-004
