USER MANUAL
EFC6620
EFC9620

Advertisement

loading

  Related Manuals for Electrolux EFC6620

  Summary of Contents for Electrolux EFC6620

  • Page 1 USER MANUAL EFC6620 EFC9620...

  • Page 3: Table Of Contents

    3 EMPFEHLUNGEN UND HINWEISE 15 RECOMMENDATIONS AND SUGGESTIONS CHARACTERISTICS CHARAKTERISTIKEN INSTALLATION MONTAGE BEDIENUNG MAINTENANCE WARTUNG CONSEJOS Y SUGERENCIAS CONSELHOS E SUGESTÕES CARACTERÍSTICAS CARACTERÍSTICAS INSTALACIÓN INSTALAÇÃO UTILIZAÇÃO MANTENIMIENTO MANUTENÇÃO TAVSIYELER VE ÖNERILER CONSIGLI E SUGGERIMENTI ÖZELLIKLER CARATTERISTICHE MONTAJ INSTALLAZIONE KULLANIM...
  • Page 4 Produkt von ly will provide you with lots of pleasure Electrolux entschieden haben, welches in the future. The Electrolux ambition is Ihnen sicherlich viel Freude bereiten to offer a wide variety of quality prod- wird. Es ist unser Bestreben, eine breite ucts that make your life more comfort- Vielfalt von Qualitätsprodukten anzubi-...
  • Page 5 Size kullanımı boyunca memnuniyet complimenti per aver scelto un elettro- vereceğini umduğumuz birinci sınıf domestico Electrolux che, siamo bir Electrolux ürünü seçtiğiniz için certi, avrà modo di apprezzare per le teșekkür ederiz. Electrolux, hayatınızı prestazioni, la qualità e l’affi dabilità e daha da konforlu hale getirecek che le renderà...

  • Page 6: Recommendations And Suggestions

    6 electrolux Recommendations and Suggestions RECOMMENDATIONS AND SUGGESTIONS Installation • Adjust the fl ame intensity to direct it onto the bottom of the pan only, mak- • The manufacturer will not be held li- ing sure that it does not engulf the able for any damages resulting from sides.

  • Page 7: Characteristics

    7 Characteristics CHARACTERISTICS Dimensions...

  • Page 8: Installation

    8 electrolux Characteristics Components Ref. Q.ty Product Components Hood Body, with: Controls, Light, Blower, Filters Telescopic Chimney: Upper Section Lower Section Reducer Flange ø 150-120 mm Flange ø 150 Air Outlet Connection Ref. Q.ty Installation Components 7.2.1 2 Upper Chimney Section Fixing...
  • Page 9 9 Installation INSTALLATION Wall drilling and bracket fi xing • Mark the wall at the centres of the holes in the bracket. Wall marking: • Mark a reference point as indicated • Draw a vertical line on the supporting...

  • Page 10: Electrical Connection

    10 electrolux Installation Hood body installation • Before attaching the hood body, tighten the two screws Vr located on the hood body mounting points. • Hook the hood body onto the screws 12a. • Fully tighten support screws 12a. • Adjust screws Vr to level the hood...
  • Page 11 11 Installation/Use Chimney assembly Upper Chimney • Slightly widen the two sides of the up- per Chimney and hook them behind the brackets 7.2.1, making sure that they are well seated. • Secure the sides to the brackets us- ing the 4 screws 12c (2,9 x 9,5) sup- plied.
  • Page 12 12 electrolux Touch Basic functions Indicator lights control Dual Function When briefl y pressed it switches the lighting Touch control Lights off system on and off. unlit When pressed for 2 seconds it starts the Touch control lit Lights on lighting system in “courtesy light”...

  • Page 13: Maintenance

    13 Maintenance MAINTENANCE Cleaning the Comfort Panels Cleaning of the Metal Cassette Filters • Pull the Comfort Panel to open it. • Disconnect the panel from the hood Alarm reset canopy by sliding the fi xing pin lever. • Stop the motor.

  • Page 14: Replacing The Charcoal Filter

    14 electrolux Maintenance Replacing the Charcoal Filter Reset the alarm signal • Stop the motor. This fi lter cannot be washed or regene- • Press the touch control F for at least rated, and must be replaced when the F 4 seconds, until the touch control T1 touch control starts to fl...
  • Page 19 436003554_01 - 061204...
