INSTALLATION & OPERATING
INSTRUCTIONS for
SPLIT SYSTEM
CONDENSING UNITS
All information contained herein is subject to change without notice.
Goodman Manufacturing Company, L.P.
I0-101G
2550 North Loop West, Suite 400, Houston, TX 77092
06/04
www.goodmanmfg.com
2003-2004 Goodman Manufacturing Company, L.P.
©
Advertisement
Table of Contents
Related Manuals for Goodman Split System Condensing Units IO-101G
Summary of Contents for Goodman Split System Condensing Units IO-101G
-
Page 1: Condensing Units
INSTALLATION & OPERATING INSTRUCTIONS for SPLIT SYSTEM CONDENSING UNITS All information contained herein is subject to change without notice. Goodman Manufacturing Company, L.P. I0-101G 2550 North Loop West, Suite 400, Houston, TX 77092 06/04 www.goodmanmfg.com 2003-2004 Goodman Manufacturing Company, L.P. ©... -
Page 2: Table Of Contents
INDEX Important Message to Homeowner ... 2 Codes and Regulations ... 2 Inspection ... 2 Replacement Parts ... 2 Important Safety Instructions ... 2 Clearances and Accessibility ... 2 Location ... 3 Electrical ... 3 Refrigerant Tubing ... 4 Evaporator Coils ... 4 Quick Connect Coils ... -
Page 3: Location
This “close to the wall” application minimizes exposed tubing and wiring and reduces the space for children to run around the unit. This will help to avoid possible damage to the tubes or wiring and/or personal injury. 10" Min. Service Access 18"... -
Page 4: Electrical
consideration is given the weather-tight integrity of the roof. The condensing unit contains moving components and can vibrate; therefore, sound is also a consideration in rooftop application. Since this unit discharges warm condenser air from the top with cooler air being drawn in three sides, plantings can be made in relatively close proximity to the unit. -
Page 5: Charge Checks
The recommended procedure for processing and charge adjustment is as follows: 1. Connect vacuum pump to both base valve service ports. 2. Evacuate tubing and evaporator through liquid and suction base valve ports, to 500 microns or less for a minimum of 30 minutes. -
Page 6: Oil Charge Adjustment
SPECIAL NOTE: Systems with MORE than 15’ of interconnecting tubing, please refer to Table 5 for line charge allowance per foot of tubing. LINE CHARGE ALLOWANCE (R-22) (oz./ft.) LINE LIQUID O. D. (IN) LINE 0.22 0.58 1.14 1.86 1 1/8 1 3/8 TABLE 5 IO-101G... -
Page 7: Wiring Diagrams
OUTDOOR CONTROL BOX HERM COMPRESSOR/FAN CAPACITOR FAN MOTOR COMPRESSOR CRANKCASE HEATER IF USED FACTORY WIRING CODE WIRING HIGH VOLTAGE LOW VOLTAGE WIRE NUT OPTIONAL START ASSIST NOTES: REPLACEMENT WIRE MUST BE SAME GAGE AND INSULATION THICKNESS, 105° C APPLIANCE WIRING MATERIAL. POWER SUPPLY (SEE RATING PLATE) USE COPPER CONDUCTORS ONLY... - Page 8 NOTE: SPECIFICATIONS AND PERFORMANCE DATA LISTED HEREIN ARE SUBJECT TO CHANGE WITHOUT NOTICE All of our systems are designed and manufactured with the same high quality standards regardless of size or efficiency. We have designed these units to significantly reduce the most frequent causes of product failure. They are simple to service and forgiving to operate.
