Whirlpool Hot water dispenser Installation Instructions And Use And Care Manual

Hot water dispenser
Hide thumbs

Advertisement

Quick Links

Installation
Instructions
AND
Use and Care
Guide
IMPORTANT:
Read and save these instructions.
IMPORTANT:
Installer: Leave this guide with
homeowner.
Homeowner: Keep this guide for
future reference. Save this guide for
local electrical inspector's use.
A Note to You
Please read the Installation Instructions
and Use and Care Guide. It contains
important information about how to install,
operate and maintain your hot water
dispenser properly and safely. Please
read it carefully.
Also, please complete and mail the
Product Registration Card provided
with your hot water dispenser. This card
helps us notify you about any new
information for your hot water dispenser.
Hot Water Dispenser
®
Record your model's information
Write down the following information about your hot water dispenser to better
help you obtain assistance or service if you ever need it. You will need to know
your complete model number and serial number. You can find this information
on the model and serial number label/plate.
If you need assistance or service, first see the "Troubleshooting" section of this
book. After checking "Troubleshooting," additional help can be found by
checking the "Requesting Assistance or Service" section.
Builder/dealer name
Address
Phone number
Model number
Serial number
Purchase date
Date installed
(See the "Parts and Features" section for model and serial number label/plate
location.)
Keep this book and your sales slip together for future reference.
Part No. 3193347
