Whirlpool HD1000XSC7 Installation Instructions And Use And Care Manual

Hot water dispenser.
Hide thumbs

Advertisement

Installation
Instructions
AND
Use and Care
Guide
IMPORTANT:
Read and save these instructions.
IMPORTANT:
Installer: Leave this guide with
homeowner.
Homeowner: Keep this guide for
future reference. Save this guide for
local electrical inspector's use.
A Note to You
Please read the Installation Instructions
and Use and Care Guide. It contains
important information about how to install,
operate and maintain your hot water
dispenser properly and safely. Please
read it carefully.
Also, please complete and mail the
Product Registration Card provided
with your hot water dispenser. This card
helps us notify you about any new
information for your hot water dispenser.
Hot Water Dispenser
®
Record your model's information
Write down the following information about your hot water dispenser to better
help you obtain assistance or service if you ever need it. You will need to know
your complete model number and serial number. You can find this information
on the model and serial number label/plate.
If you need assistance or service, first see the "Troubleshooting" section of this
book. After checking "Troubleshooting," additional help can be found by
checking the "Requesting Assistance or Service" section.
Builder/dealer name
Address
Phone number
Model number
Serial number
Purchase date
Date installed
(See the "Parts and Features" section for model and serial number label/plate
location.)
Keep this book and your sales slip together for future reference.
Part No. 3192760

Advertisement

Table of Contents

   Related Manuals for Whirlpool HD1000XSC7

   Summary of Contents for Whirlpool HD1000XSC7

  • Page 1 Installation Instructions Use and Care Guide IMPORTANT: Read and save these instructions. IMPORTANT: Installer: Leave this guide with homeowner. Homeowner: Keep this guide for future reference. Save this guide for local electrical inspector’s use. A Note to You Please read the Installation Instructions and Use and Care Guide.
  • Page 2: Table Of Contents

    A Note to you ... . Cover Hot Water Dispenser Safety ..2 Parts and Features ... 3 How your hot water dispenser works .
  • Page 3: Parts And Features

    How your hot water dispenser works Water is electrically heated to a brewing/cooking hot 190°F by a tank that mounts under the sink. A thermostat maintains it at this approximate temperature. When you turn the On/Off Cap, cold water Use this hot water dispenser illustration to help you quickly learn how to install and use your new hot water dispenser.
  • Page 4: Before You Start

    Important: Observe all governing codes and ordinances. 42" max. — electrical outlet to hot water dispenser tank. Before You Start Check location where hot water dispenser will be installed. Proper installation is your responsibility. Make sure you have everything necessary for correct installation. It is the responsibility of the installer to comply with installation specifications and with state and local plumbing...
  • Page 5: Tools And Materials Needed

    Tools and materials needed ruler or measuring tape pliers pencil gloves flat-blade screwdriver safety glasses tubing cutter 1/4" drill bit hand or electric drill open-end wrench(es) to fit saddle valve 1/4" O.D. copper tubing bucket or pan 2 mounting bracket screws (and 2 plastic anchors if attaching to dry wall) Saddle valve kit to fit...
  • Page 6: Installation Instructions

    On/Off Cap Installation Instructions Numbers correspond to steps. NOTE: Do NOT plug power supply cord into outlet. Put on gloves and safety glasses. Determine where you will install your hot water dispenser. Check below sink to assure that reinforcing ribs, support brackets or cabinet construction will not interfere with spout.
  • Page 7 gasket mounting screw square bracket 2-1/4" bracket position Installation Instructions cont. NOTE: Do NOT plug power supply cord into outlet. Lay spout assembly on flat surface with coiled tubing facing up. Using one hand to hold tubing just below spout, carefully straighten tubing with other hand.
  • Page 8 quick- connect fitting collet clamp clear tubing closed open Installation Instructions cont. NOTE: Do NOT plug power supply cord into outlet. Connect 1/4" spout tubing (longer tubing) to the rear quick- connect fitting on top of tank. Push tubing straight into fitting as far as it will go.
  • Page 9 water supply line quick-connect fitting copper tubing saddle valve Installation Instructions cont. Connect water supply line from saddle valve to spout copper tubing with the factory-assembled quick-connect fitting. Push water supply line tubing straight into fitting as far as it will go. Pull on tubing. The tubing should not come out when properly installed.
  • Page 10: Using Your Hot Water Dispenser

    Using Your Hot Water Dispenser Before using the first time Check that installation Steps 14-16 were completed. The hot water dispenser can be permanently damaged if these steps are not followed. Temperature control The water temperature is thermostatically controlled. It can be adjusted from “Off”...
  • Page 11: Caring For Your Hot Water Dispenser

    O-ring screw screws base plate Caring For Your Hot Water Dispenser Energy-saving tips and preparation for periods of nonuse On average, you will use your hot water dispenser to heat 7 to 8 cups of water per day. This uses only 19 kilowatt-hours of energy per month.
  • Page 12: Troubleshooting

    Before calling for service... If hot water dispenser does not operate, check these points first: Has circuit breaker tripped or house fuse blown? Is power supply cord plugged If you need more help, check the chart below. This could save you the cost of a service call for a problem that is not covered by the warranty.
  • Page 13: Requesting Assistance Or Service

    Yellow Pages under: 3. If you need FSP replacement parts … ® FSP is a registered trademark of Whirlpool Corporation for quality parts. Look for this symbol of quality when- ever you need a replacement part for your WHIRLPOOL ®...
  • Page 14: Warranty

    This warranty gives you specific legal rights, and you may also have other rights which may vary from state to state. Outside the United States, a different warranty may apply. For details, please contact your authorized Whirlpool dealer. If you need service, first see the “Troubleshooting Guide” section of this book. After checking the “Troubleshooting Guide,”...
  • Page 16 Part No. 3192760 ©1999 Whirlpool, U.S.A. ®Registered Trademark of Whirlpool, U.S.A. Printed in U.S.A...
