M8 Nylon
M10 Nylon
Frame Spacer (83)–1
Locknut (46)–4
Locknut (29)–6
M4 x 16mm
M10 Split
M10.3 Black
M10
Screw (66)–2
Washer (70)–4
Washer (53)–2
Washer (38)–6
Adjustment Bolt (20)–2
M8 x 19mm Shoulder
M10 x 27mm
Screw (22)–2
Screw (71)–3
M10 x 78mm Button Bolt (27)–2
M8 x 45mm Button Bolt (50)–4
M10 x 88mm Button Screw (63)–1
M10 x 112mm Carriage Bolt (34)–4
