- Page 1 IWA Series Remote Control PCB Installation & Operation Biamp Systems, 10074 S.W. Arctic Drive, Beaverton, Oregon 97005 U.S.A. (503) 641-7287 http://www.biamp.com an affiliate of Rauland-Borg Corp.
-
Page 2: Remote Control
REMOTE CONTROL REMOTE CONTROL PCB MIXER PCB The IWA Series can be remotely controlled via infrared, wall-mount, or custom controls (see pages 2 & 3). Remote control capability is provided stand-offs by an optional (user installed) Remote Control PCB (printed circuit board). - Page 3 REMOTE CONTROLS The IWA Series can be remotely controlled via infrared, wall-mount, and/or custom controls. An internal infrared receiver is provided on the Remote Control PCB (for set-up purposes only). The actual remote controls are offered optionally. This allows the user to select the type and quantity of remote controls necessary for a particular application.
- Page 4 Wall-Mount Panel. Remote Interface Kit (Biamp #909-0041-00): The Remote Interface Kit allows the user to create a customized control panel, using his own switches, enclosure, and panel. It can provide up to 40 buttons (12 more than standard remote controls). The Remote Interface Kit is a tested circuit board assembly, which includes two wiring harnesses.
