- Page 1 ® ® Audia & Nexia RED-1 & RED-1F Operation/Installation Manual Biamp Systems, 9300 SW Gemini Drive, Beaverton, OR 97008 U.S.A. (503) 641-7287 www.biamp.com...
-
Page 2: Table Of Contents
TABLE OF CONTENTS REMOTE ETHERNET DEVICE 1 (RED-1) FEATURES ........ -
Page 3: Remote Ethernet Device 1 (Red-1) Features
• RED-1 surface mounts or flush mounts to most walls with a wide variety of mounting holes to accommodate standard US and international back boxes. RED-1F flush-mounts to any wall; mounts using the retrofit plate (included) or installs in a Raco ®... -
Page 4: Setup And Use
Setup and Use The Audia and Nexia software provides an intuitive interface for setup and programming of the RED-1. The information supplied by this manual relates to physical connections and device setup. For more details on software setup, please consult the Audia or Nexia Help File. -
Page 5: Back Panel
Ethernet. The RED-1 is powered using IEEE 802.3-2008 Power over Ethernet protocol as Class 1 devices. Either a PoE-capable network switch or a PoE injector is required to power the device; there are no other provisions for power inlet. -
Page 6: Set Up
Device Setup Mode The RED-1 can be configured without connecting to a functional Audia or Nexia network. To enter setup mode, connect the RED-1 to a PoE source and place the jumper or any metal object across the locksmith pins. When configuration is complete, remove the jumper and attach it to only one pin to resume normal operation. -
Page 7: Edit Network Configuration
To edit the network configuration, scroll to the Network icon and press the Select button. The default setting (Static) initializes the IP address to 192.168.1.201, network mask to 255.255.255.0, and gateway to 0.0.0.0. These default settings allow RED-1 to be discovered by an Audia or Nexia device that also has default settings. -
Page 8: Edit Display Brightness
RED-1 SET UP Edit Display Brightness To change the brightness of the OLED panel, scroll to the Display Brightness icon and press the Select button. Use the scroll wheel and Select button to make adjustments. The first setting represents the normal operational display brightness, and the second setting represents the dim display brightness. -
Page 9: Installation
UK, Netherland Use a screw driver or other suitable tool to engage the latch at the bottom of the RED-1 to detach the back enclosure. When installing the RED-1 using the RJ45 connector, guide the Ethernet cable through the rear opening before attaching the RED-1 to the wall. Connect the RJ45 and snap the front enclosure into the retention holes. - Page 10 RED-1 INSTALLATION Flush Mount Installation The RED-1F may be flush mounted using the retro-fit plate (provided with the product) or a Raco™ 254 box (purchased from an electrical distributor). To install the RED-1F, a hole must be cut in the wall to accommodate the Raco™ 254 back-box or to use the retro-fit plate. See the figures below.
- Page 11 RED-1 INSTALLATION Retro-Fit Plate Raco™ 254 Trim Ring Front Plate Exploded view showing pieces required for mounting to the retro-fit plate or the Raco™ 254 back-box When installing the RED-1F using the retro-fit plate or the back-box, fasten the trim ring using the four screws provided to either the retro- fit plate or the back-box.
- Page 12 Software support in Audia configuration software Version 5.1 and Nexia Version 3.1 or later provides user programming of all remote functions, network setup, device naming, and device maintenance. Visit www.biamp.com/support.php to obtain firmware and software updates related to this product. To speak with a Product Applications Engineer, please call 1-800-826-1457 or email support@biamp.com.
-
Page 13: Specifications
RED-1 SPECIFICATIONS SPECIFICATIONS (RED-1) Dimensions (Length x Width x Depth): 5.1 inches x 4.7 inches x 1.25 inches (130mm x 120mm x 32mm) Weight: 0.5 lb Power consumption: PoE Class 1 (3.2W max) Material: PC/ABS Control cable requirements: Unshielded twisted pair (UTP) wiring, 100BaseT interface using either RJ45 or Insulation Displacement Connector (IDC) Control cable length: 330 ft. -
Page 14: Warranty
9. BIAMP Systems shall not be liable for special, indirect, incidental, or consequential damages, including lost profits or loss of use arising out of the purchase, sale, or use of the products, even if BIAMP Systems was advised of the possibility of such damages. - Page 15 DIRECTIVES below except as noted herein. Any alterations to the product not agreed upon and directed by Biamp Systems Corporation will invalidate this declaration. Product Models: RED-1, RED-1F Product Description: Control Accessories for use with audio DSPs.
- Page 16 EU RoHS COMPLIANT This Biamp product, including all attendant cables and accessories supplied by Biamp, meets all requirements of EU Directives 2002/95/EC of January 27, 2003, and 2005/618/EC of August 18, 2005, the EU RoHS Directives. An EU RoHS Materials Content Declaration document may be obtained at www.biamp.com...
