TM
Remote Translator
–––– and ––––
WMC, IR-T, & RIK
Controls
Operation Manual
INTRODUCTION
pg. 2
The RT Remote Translator allows remote control of BIAMP programmable
products, such as VRAM, MSP22e, & SPM723, via standard wall-mount &
pg. 3
infrared controls, including WMC, IR-T, & RIK. The RT converts control button
data into RS-232 characters, which can be programmed on a per product
pg. 5
basis. Therefore, controls can be customized to control a variety of level,
muting, source selection, & recall preset functions within a system having
pg. 8
multiple BIAMP products. The RT carries a five-year warranty.
pg. 9
RT features include:
RT
♦ RS-232 serial & link ports for communication with products
♦ 2 remote ports accept any combination of standard controls
♦ supports Biamp standard controls (WMC, IR-T, & RIK)
♦ WMC - 2-gang wall-mount control panel (28 buttons)
♦ RIK - circuit board for custom-built panels (up to 40 buttons)
♦ IR-T - hand-held infrared transmitter control (28 buttons)
♦ individual product software assigns functions to push-buttons
♦ power & data LED indicators for easy trouble-shooting
♦ back panel key-holes provided for convenient mounting
♦ covered by Biamp Systems' five-year warranty
♦ incorporates AES recommended grounding practices
♦
marked and UL / C-UL listed power source
1
Advertisement
Related Manuals for Biamp Advantage RT
Summary of Contents for Biamp Advantage RT
- Page 1 TABLE OF CONTENTS INTRODUCTION Connections pg. 2 The RT Remote Translator allows remote control of BIAMP programmable products, such as VRAM, MSP22e, & SPM723, via standard wall-mount & RS-232 pg. 3 infrared controls, including WMC, IR-T, & RIK. The RT converts control button...
- Page 2 Link Port: This 9-pin Sub-D (female) connector provides a Link Port for RS-232 control from the RT to other BIAMP programmable products (see RS-232 on pg. 3). The Link Port of one device simply connects to the Serial Port of the next device (and so forth).
- Page 3 38,400. This baud rate corresponds with the current default baud rate of the most commonly associated Biamp programmable products. However, in some cases the RT baud rate may need to be changed to match that of other devices being used in the system.
- Page 4 Link Port Connections: The 9-pin Sub-D (female) connector provides the RS-232 compatible serial interface signals used for RT control of BIAMP programmable products within a system. The Link Port of one device simply connects to the Serial Port of the next device, and so forth (see diagram below).
- Page 5 CONTROLS Wall-Mount Panel (WMC) Biamp #909-0076-00: The WMC is a "hard-wired" control, which receives power from the RT. There are no batteries to wear out, and it is not easily lost or stolen. The WMC may be wired up to 2000 feet from the RT, using 2-conductor shielded cable (not included).
- Page 6 (such as TVs or VCRs). Likewise, other infrared controllers will not provide proper control of Biamp equipment. The IR-T requires two AAA batteries, which are included with the unit (user installed). The IR-T has twenty-eight buttons. For programming purposes, these buttons are given reference numbers 1~28, starting at the bottom and going left-to-right (see diagran at right).
- Page 7 Advantage product it is controlling. Connect the cable shield to the WALL-MOUNT REMOTE "GND" terminal at each end. Use BIAMP SYSTEMS the two conductors to connect "IR2" to "IR2" and "IR3" to "IR3". The Wall-Mount has an infrared detector WALL-MOUNT which may be disabled via the circuit board jumper strap labelled "IR...
- Page 8 APPLICATIONS PRESENTATION ROOM system setup or control IR-T ADVANTAGE RT SELECT SELECT Remote Translator 50/60 Hz serial port MUTE MUTE MUTE MUTE MUTE MUTE MUTE MUTE 15 watts power data class 2 wiring link port remote 1 remote 2 MUTE...
- Page 9 WARRANTY BIAMP SYSTEMS IS PLEASED TO EXTEND THE FOLLOWING 5-YEAR LIMITED WARRANTY TO THE ORIGINAL PURCHASER OF THE PROFESSIONAL SOUND EQUIPMENT DESCRIBED IN THIS MANUAL. BIAMP Systems expressly warrants this product to 4. BIAMP SYSTEMS SHALL NOT IN ANY EVENT BE...
- Page 10 Declaration of Conformity Biamp Systems, Inc., as the manufacturer, hereby declares that the following described product, in our delivered version, complies with the provisions of the DIRECTIVES except as noted herein. In case of alteration of the product, not agreed upon or directed by us, this declaration is no longer valid.
