5. Tonebone Classic Function Overview

DRIVE control: Used to adjust overall amount of input gain &
1
distortion. For even more drive, use the
GAIN switch: Used to boost the gain at preamp input.
2
= +9dB
MED
at 9:00 o'clock and
DRIVE
FILTER control: Used to balance the high frequency ratio between
3
the amplifier and the ToneBone. Hint: start adjustments at the
full clockwise position and work backwards.
MID BOOST switch: Gives you +7dB & +12dB boost @ 360Hz.
4
Allows guitar to cut through the mix; especially useful for soloing.
LOW control: Active 'post-distortion' tone control. Boost or cut ±14.5
5
dB @ 100 Hz from 12 o'clock position.
TOP END switch:
6
recommended position when the amp's bright switch is on;
-6dB @ 3.3KHz, normally used with super bright inputs.
DARK:
HIGH control: Active 'post-distortion' tone control. Boost or cut
7
±10dB @ 4.3KHz from 12 o'clock position.
LEVEL control: This is used to adjust the output level without alter-
8
ing any of the tonal characteristics.
FOOTSWITCH: Toggles between effect and True-Bypass. i.e.
9
when the Tonebone is off, the signal passes straight through without
any effect. An on/off status indicator LED is provided.
3
= +20dB. Hint: Start with GAIN in low position and
HIGH
LEVEL
BRIGHT:
switch.
GAIN
at 3:00. Then add
+6dB @ 10KHz;
FLAT
True to the Music
= 0dB
LOW
.
DRIVE
is the
