Summary of Contents for Electrolux EFC1420
- Page 1 Gebrauchsanweisung , Notice d'utilisation et d'installation, Installatie- en gebruiksaanwijzing EFC 1460 EFC 1420 User manual, Istruzioni per l'uso, Instrucciones de montaje y manejo, Manual de Instruções EFC 1420 EFC 1460...
-
Page 2: Table Of Contents
Contents Safety warnings ..............................42 For the installer ..............................42 For the user ................................42 Description of the Appliance .......................... 43 Extractor version ..............................43 Filter Version ................................. 43 Control Panel - EFC 1460 ..........................43 Control Panel - EFC 1420 ..........................44 Maintenance and care ............................ -
Page 3: Safety Warnings
Safety warnings For the installer conditions without the need for any of the aforementioned measures. • When used as an extractor unit, the hood must • When the hood is used in its extractor function, be fitted with a 150mm diameter hose. the following rules must be followed to obtain Only for model EFC 1460 X / 942 120 706: optimal operation:... -
Page 4: Description Of The Appliance
• The hood is supplied as an extractor unit and can also be used with a filtering function by fitting one charcoal filter. • You will need an original ELECTROLUX Coupling ring charcoal filter for this function (Available from your local ELECTROLUX Service Force Centre). -
Page 5: Control Panel - Efc 1420
Control Panel - EFC 1420 • Best results are obtained by using a low speed for normal conditions and a high speed when odours are more concentrated. Turn the hood on a few minutes before you start cooking, you will then get an under pressure in the kitchen. The hood should be left on after cooking for about 15 minutes or until all the odours have disappeared. -
Page 6: Maintenance And Care
Maintenance and care • The hood must always be disconnected from the electricity supply before beginning any maintenance work. Cleaning the hood Warning • Clean the outside of the hood using a damp • Failure to observe the instructions on cleaning cloth and a mild detergent. -
Page 7: Charcoal Filter
• The charcoal filter should only be used if you want to use the hood in the recirculation function. • To do this you will need an original ELECTROLUX charcoal filter (available from your local Service Force Centre). • Cleaning/replacing the carbon filter Unlike other carbon filters, the LONGLIFE carbon filter can be cleaned and reactivated. -
Page 8: What To Do If
What to do if If your appliance fails to work properly please carry out the following checks. Symptom Solution The cooker hood will not start... Check that: The hood is connected to the electricity supply. Check that a fan speed has been selected The cooker hood is not working Check that: The fan speed is set high enough for the task. -
Page 9: Technical Assistance Service
In the event of your appliance requiring service, or if you wish to purchase spare parts, contact your local ELECTROLUX Service Force Centre by telephoning: 08705 929 929 Your call will be automatically routed to the Service Centre covering your post code area. For the address of your local Service Force Centre and further information about Service Force, please visit the website at www.serviceforce.co.uk... -
Page 10: Installation
Installation Unpacking Check that the cooker hood has no damages. Transportation damages should immediately be reported to the one responsible for the transport Damages, faults and eventually missing details should immediately be reported to the seller. 65 cm Take care of the packing material so that small 50 cm children cannot play with it. -
Page 11: Mounting Accessories Included
Fig. 9a. Flange Installation of the support structure extension (only for model EFC1420 - PNC 942 120 788): In the instance where a longer support structure Extension may be required (for example in cases of... -
Page 12: Mounting
Installation Mounting - Fig. 10-11-12 Expansion plugs are provided to secure the hood to most types of ceilings. However, a qualified technician must verify suitability of the materials in accordance with the type of ceiling. The ceiling must be strong enough to take the weight of the hood. - Page 13 • For extractor versions (13A), connect the other end of the exhaust pipe to the flue. For filter versions (13F), fit deflector F to the truss and secure it to the bracket supplied using 4 screws, then connect the exhaust pipe to the connection ring located on the deflector. •...
- Page 14 • Join the two bottom sections of the flue covering the truss (18) using 6 screws (3 each side, see the plan diagram for joining the two sections). • Insert the bottom section of the flue in its seat so that it completely covers the motor compartment and electrical connection box, then ensure it from inside the hood using two screws (19).
- Page 15 LI1YAF Ed. 05/03...
