Summary of Contents for Electrolux EFC 1460
- Page 1 Gebrauchsanweisung , Notice d'utilisation et d'installation EFC 1460 Installatie- en gebruiksaanwijzing , User manual...
-
Page 2: Table Of Contents
Contents Safety warnings for the installer for the user Description of the appliance Extractor version Filter Version Control Panel Correct ventilation If the hood does not function Before you make contact to service Service and spare parts Maintenance and care Cleaning Metal grease filter Open the metal grease filter... -
Page 3: Safety Warnings
Safety warnings for the installer is to say a larger hole, could reduce the perfor- mance of the extractor hood. • When used as an extractor unit, the hood must • If the hood is used in its filtering function, it will be fitted with a 150mm diameter hose. -
Page 4: Description Of The Appliance
• The air is filtered through a charcoal filter and returned to the kitchen through the top grill of the outlet pipe. • You will need an original ELECTROLUX KF20 charcoal filter for the filtering function. (See Special Accessories). • Fix the deflector using 4screws Ø3x9mm . Fig. -
Page 5: Control Panel
Control Panel • The hood is fitted with one motor having several speed. Turn the hood on a few minutes before you start cooking, you will then get an under pressure in the kitchen. The hood should be left ON/OFF on after cooking for about 15 minutes or until all Extractor fan the odours have disappeared. -
Page 6: Maintenance And Care
Maintenance and care The hood must always be disconnected from the electricity supply before beginning any maintenance work. Cleaning Warning • Warning: always disconnect the hood from the • Failure to observe the instructions on cleaning mains power supply before cleaning it. the unit and changing the filters will cause a fire Never insert pointed objects in the motor’s hazard. -
Page 7: Charcoal Filter
• The charcoal filter should only be used if you want to use the hood in its filtering function. • To do this you will need an original ELECTROLUX charcoal filter (see special accessories). • Cleaning/replacing the carbon filter Unlike other carbon filters, the LONGLIFE charcoal filter can be cleaned and reactivated. -
Page 8: Technical Specifications
Technical Specifications Dimensions (cm) Height 85,8 - 113 Width 99,8 Depth Lighting 4 x 20 W Grease filter power absorption 240 W We reserve the right to generate constructive and chromatic modifications as required by technological growth. Special accessories Carbon filter KF 20 E-Nr. -
Page 9: Mounting Accessories Included
Installation Mounting accessories included 1 deflector, 6 wood-screws 6 x 70 mm, 6 wall plugs Ø 10 mm, 10 nuts, 8 metal screws 3x9 mm, 6 metal screws 4 x 8 mm, 10 metal screws 3x9 mm, 1 reduction flange Ø 125-120 mm Wall unit mounting - Fig. - Page 10 • For extractor versions (13A), connect the other end of the exhaust pipe to the flue. For filter versions (13F), fit deflector F to the truss and secure it to the bracket supplied using 4 screws, then connect the exhaust pipe to the connection ring located on the deflector. •...
- Page 11 • Join the two bottom sections of the flue covering the truss (18) using 6 screws (3 each side, see the plan diagram for joining the two sections). • Insert the bottom section of the flue in its seat so that it completely covers the motor compartment and electrical connection box, then ensure it from inside the hood using two screws (19).
- Page 14 LI1YAB Ed.05/02...
