- Page 1 3VCA A Celeron Soc et 370 Pr ocessor based 4X AGP motherboard (133/100/ 6VBA2 Processor based 4X AGP motherboard TRADEMARK All products and company names are trademarks or registered trademarks of their respective holders. These specifications are subjected to change without notice.
- Page 2 3VCA/6VBA2 Features 3VCA/6VBA2 Features: • 3VCA is based on the Intel CeleronTM Processor operating at 300 ~ 600MHz on PGA370. The board is configured by an ESSJ (Easy-Setting- Single-Jumper) to match your CPU clock speed. ® • 6VBA2 is based on the Pentium II/III Processor operating at 266 ~ 733MHz on Slot1.
- Page 3 BIOS as they are released. (http://www.2themax.com/ please visit our Technical Support section for the latest updates). • 3VCA/6VBA2 utilizes a Lithium battery which provides environmental protection and longer battery life. • Supports the (4) Universal Serial Bus (USB) Ports. The onboard VT82C686A chip provides the means for connecting PC peripherals such as;...
- Page 4 3VCA/6VBA2 Installation 3VCA Detailed Layout Page 4...
- Page 5 3VCA/6VBA2 Installation 6VBA2 Detailed Layout Page 5...
-
Page 6: Installation
3VCA/6VBA2 Installation The following must be completed before powering on your new system: Configured Jumpers System memory Configuration Device Connectors We design this motherboard with the fewest jumpers to make your installation fast and easy. The following will describe all of the jumpers that you are required to set before moving on to step 2. - Page 7 3VCA/6VBA2 Installation The 3VCA/6VBA2 supports (3) PC133 168-pin DIMMs (Dual In-line Memory Module). The DIMMs can be either EDO (Enhanced Data Out) or SDRAM (Synchronized DRAM). • DIMM SDRAM may be 83MHz (12ns), 100MHz (10ns) or 125MHz (8ns) bus speed.
- Page 8 3VCA/6VBA2 Installation Please install the motherboard into the chassis. Now that your motherboard is installed you are ready to connect all your connec- tions (figure 7). Joystick/Midi port parallel port PS/2 Mouse USB port PS/2 KEYBOARD COM1 COM2 Speaker Line_in...
- Page 9 3VCA/6VBA2 Installation (This is connected to the power button on the case. Using the Soft-Off by Pwr-BTTN feature, you can choose either Instant Off (turns system off immediately), or 4 sec delay (you need to hold the button down for 4 seconds before the system turns off).
