READ THE INSTRUCTIONS CAREFULLY TO MAKE THE MOST OF YOUR APPLIANCE.
We recommend you keep the instructions for installation and use for later reference, and before installing the appliance, note its serial
number below in case you need to get help from the after sales service.
. Identification plate is located at the back of the Duo.
THE COMPANY SHALL NOT BE LIABLE IF THE INSTRUCTIONS PROVIDED IN THIS DOCUMENT ARE NOT
COMPLIED WITH.

SAFETY INSTRUCTIONS

You should entrust the electrical connection of your
appliance to an approved installer or technician with similar
qualifications.
The DUO consists of two elements an oven and a diswasher.
For safety reasons under no circumstances should any
modifications be carried out to this appliance.
This appliance is designed for domestic use only.
If the DUO shows even the smallest defect, do not connect it.
Disconnect from the power supply and immediately contact an
approved service agent.
There are certain basic safety rules which are valid for any
domestic appliance. They are the following :
- Never touch the appliance when your hands or feet are wet or
damp.
- Do not use it when your feet are bare.
- Do not remove the plug from the mains supply socket by pulling
the mains cable or the machine itself.
- Do not leave the appliance exposed to the elements (rain, sun etc...).
- Do not let children (or others incapable of operating it) use the
machine without supervision.
- Do not lean on the doors or not allow children to do so.
• This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance
by a person responsible for their safety.
• Children should be supervised to ensure that they do not play
with the appliance.
All accessible parts are hot when the DUO is in operation. Keep
young children away from the appliance when in use.
After each use we recommend that some cleaning of the DUO
is undertaken. This prevents the accumulation of dirt or grease
which gets re-cooked and burns, generating unpleasant smells
and smoke.
Never use a steam or high pressure spray to clean the appliance.
Do not store flammable products in the DUO as they can catch
fire if the appliance is inadvertlanty switched on.
Use oven gloves when placing or removing a dish from the oven.
Do not line the oven walls with aluminium foil or single-use oven
protectors available from some stores. Aluminium or any other
protection, in direct contact with the hot enamel, risks melting
the enamel or causing deterioration to the inside.
When cooking with fats or oils, always take care to watch the
cooking process as heated fats and oils can catch fire rapidly.
The dishwasher is designed for normal kitchen utensils. Objects
that have been contamined by petrol, paint, traces of steel or
iron, corrosive chemicals, acids or alkalis must not be washed
in the dishwasher.
There should not be water left in the machine or on the dishes
at the end of the wash programme.
If you wish to dispose of an old dishwasher be careful to remove
the door to eleminate the risk of children becoming trapped
inside it.
The dishwasher has been made from materials which can be
recycled so that it can be disposed of in an environmentally
friendly way.
Ensure that the dishwasher does not crush power cables.
It is not advisable to use adaptors, multiple plugs and/or extension
cables.
Any queries regarding the power supply cord should be referred
to After Sales Service or a qualified technician.
When the appliance is located on a carpet floor, attention must
be paid to ensure that there is no obstructions to the bottom vents.
Any failure to follow the above advice may have serious
consequences for the safety of the appliance.
We recommend during the installation of the appliance on a base
to verify the stability and to take the necessary measures to avoid
a possible sliding.
In order to improve the quality of the products, CANDY
may carry out modifications linked to technical
improvements.
Appliance complies with European Directives 73/23/EEC and
89/336/EEC, replaced by 2006/95/EC and 2004/108/EC, and
subsequent amendments.

TECHNICAL DATA

Power
Place settings
Water consumption
2 GB
DUO
2100 W
6
9 lt

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DUO609X and is the answer not in the manual?

Questions and answers

Summary of Contents for Candy DUO609X

  • Page 1: Safety Instructions

    The DUO consists of two elements an oven and a diswasher. In order to improve the quality of the products, CANDY For safety reasons under no circumstances should any modifications be carried out to this appliance.
  • Page 2: Installation

    INSTALLATION Installing a domestic appliance can be a complicated operation which if not carried out correctly, can seriously affect consumer safety. It is for this reason that a professionally qualified person should undertake the task who will carry it out in accordance with the technical regulations in force.
  • Page 3: Oven Equipment

    THE OVEN USE • Press the "On/Off" VERY IMPORTANT : the oven and the dishwaher cannot be The first oven light bulb of the programs lights up in on position, used at the same time. To use the oven, you have to close the dishwasher. with all displays are off in light bulb mode.
  • Page 4 COOKING ADVICES MEAT : It is better not to salt meats until after cooking as salt encourages the meat to splatter fat. This will dirty the oven and make a lot of smoke. Joints of white meat, pork, veal, lamb and fish can be put into the oven cold. The cooking time is longer than in a preheated oven, but it cooks through to the centre better as the heat has more time to penetrate the joint.
  • Page 5 THE DISHWASHER Technical data : Place load EN50242 Drainage pump power 30 W Capacity with pans & dishes 4 persons Max power absorbed 2050 W Water supply pressure (litres) 3 Water pressure mini 0,08 - max 0,8 MPa Power 1900 W Wash pump power 150 W Fuse (amp)
  • Page 6: Loading Dishes

    LOADING DISHES FILLING THE RINSE AID DISPENSER The basket has been carefully designed to make loading easy. The rinse aid dispenser "B" is to the right of the detergent dispenser For good wash performance, remove any debris from the dishes and has a capacity of about 130 ml.
  • Page 7: Washing Programme

    Regulating the water softener with electronic programmer The water softener can treat water with a hardness level of up to 60°Fh (French grading) or 33°Dh (German grading) through 5 settings. The settings are listed in the panel below: Water hardness Water hardness Use of regenerating Water softener...
  • Page 8: What To Do If

    SOME PRACTICAL HINTS ..- To carry out a wash programme with a full load of dishes load the machine correctly after each meal and do a cold pre-wash between each load to get rid of stains and remove the larger residues of food. HOW TO GET GOOD WASH RESULTS 1) Place the dishes face downwards.
  • Page 9: Troubleshooting

    TROUBLESHOOTING REMEMBER! the oven and the dishwasher cannot be used in the same time. Should the dishwasher fail to operate, before contacting the Service Centre, make the following checks: FAULT CAUSE REMEDY Plug is not connected correctly Connect electric plug O/I button has not been pressed Press button 1 - Machine completely dead...
