Specifications - Infinity CLASSIA C255ES Owner's Manual

S
PECIFICATIONS
C255ES
Frequency Range: 60Hz – 30kHz (–3dB)
50Hz – 40kHz (–6dB)
Recommended
Amplifi er Power Range: 10 – 150 Watts
Sensitivity (2.83V @1 meter): 87dB
Nominal Impedance: 8 Ohms
Crossover Frequency: 2.3kHz; 24dB/octave
Low-Frequency Drivers: Dual 5-1/4" (133mm) CMMD
High-Frequency Drivers: Dual 1" (25mm) CMMD
Dimensions (H x W xD): 11-3/4" x 13-1/4" x 6-1/2"
(298mm x 337mm x 165mm)
Weight: 9.1 lb (4.1kg)
Features,specifi cations and appearance are subject to change without notice.
®
We,Harman Consumer Group, Inc.
declare in own responsibility that the product described in this
owner's manual is in compliance with technical standards:
EN 61000-6-3:2001
EN 61000-6-1:2001
Declaration of Conformity
2, route de Tours
72500 Château du Loir
France
Laurent Rault
Harman Consumer Group, Inc.
Château du Loir, France 12/07
INFINITY CLASSIA C255ES
7
