Infinity C205 Classia Technical Manual

Technical Manual
C205 Infinity Classia
ACOUSTIC & ELECTRICAL SPECIFICATIONS:
• Nominal Impedance
• Max Amp Power
• Frequency Response
• Sensitivity
• Crossover Frequency
SYSTEM COMPONENTS:
• Grille
• Low-Frequency Transducer
DC Resistance
• High-Frequency Transducer
DC Resistance
• Crossover Network
PACKAGING
16
17
20
21
22
23
24
25
Release Date 2008
Discontinued Date XXXX
Harman Consumer Group, Inc., 250 Crossways Park Drive, Woodbury, New York 11797
8 Ohms
125 Watts*
60Hz – 30kHz (–3dB)
55Hz – 40kHz (–6dB)
88dB (2.83V @ 1 meter)
2.0kHz (24dB/octave)
NT-13333-01
5-1/4" (133mm) CMMD ®
magnetically shielded
(130W33601)
4.4 Ohms, ±10%
1" (25mm) CMMD ®
magnetically shielded
(025D38501)
3.7 Ohms, ±10%
FL-13333-01S
26
18
19
20
Legend on Page 2
™
AURAL SWEEP TEST SPECIFICATIONS:
System Aural Sweep Test
•
• L.F. Aural Sweep Test
• H.F. Aural Sweep Test
PHYSICAL SPECIFICATIONS:
Dimensions
•
(H x W x D)
• Weight
WARRANTY:
• Refer to Warranty Statement packed with each product.
*
The maximum recommended amplifier power rating will ensure
proper system headroom to allow for occasional peaks. We do not
recommend sustained operation at these maximum power levels.
WIRING DIAGRAM
Red +
Black –
CROSSOVER NETWORK
FL-13333-01S
C205 SCHEMATIC
L1
1.5mH
24
INPUT
R2
4Ω
5W
C3
3.0μF
100V
6.0V Input 60Hz to 20kHz
5.0V Input 60Hz to 3kHz
2.83V Input 1kHz to 20kHz
15-1/8" x 7-1/2" x 9-1/4"
(384mm x 190mm x 235mm)
10.8 lb/4.9kg (each)
LOW-FREQUENCY
TRANSDUCER
130W33601
Red +
Black –
Green +
Black –
HIGH-FREQUENCY
TRANSDUCER
025D38501
Red 305mm
.250
L2
0.28mH
R1
5.1Ω
5W
C1
5.6μF
C2
100V
10μF
100V
Black 305mm
.205
Green 255mm
.205
C4
3.3μF
100V
L3
0.3mH
Black 255mm
.110
L.F.
H.F.
6/08
