Introduction
Your new GMC laser hand tool will more than satisfy your
expectations. It has been manufactured under stringent
GMC Quality Standards to meet superior performance
criteria.
You will find your new tool easy and safe to operate,
and, with proper care, it will give you many years of
dependable service.
Caution.
Carefully read through this entire Instruction
Manual before using your new GMC laser hand tool. Take
special care to heed the Cautions and Warnings.
Your GMC laser hand tool has many features that will
make your job faster and easier. Safety, performance,
and dependability have been given top priority in the
development of this tool, making it easy to maintain
and operate.
Environmental protection
Recycle unwanted materials instead of
disposing of them as waste. All tools, hoses
and packaging should be sorted, taken to
the local recycling centre and disposed of
in an environmentally safe way.
Description of symbols
The rating plate on your tool may show symbols. These
represent important information about the product or
instructions on its use.
Conforms to relevant standards for
electromagnetic compatibility.
Do not stare into beam. Only turn laser beam
on when tool is on work piece. Class 2 laser
product.
Specifications
Recommended Use:
Length of laser line:
Laser diode type:
Laser class:
Operation area:
Laser fan beam angle: 100°
Power supply:
Battery life:
Operation temperature: -1°C to 40°C
Dimensions:
Weight:
Accuracy:
Laser radiation is emitted from the
CAUTION.
line generator.
3
Indoor
Up to 10m
Red laser diode 650nm
Class 2, maximum power
output less than or
equal to 1mW
Up to 10m distance and/or up
to 10m length of visible laser line
(with help of red laser enhancing
glasses, indoor)
2 x AA – 1.5 volt batteries
(not supplied)
40 hours of continuous use
with alkaline batteries
115mm x 54mm x 80mm
Unit only (no batteries) 240g
Base
Batteries
+/- 13mm at 10m
90g
50g
