- Page 1 INSTRUCTION MANUAL Hammer Drill • Melbourne • Perth • Auckland • Hong Kong • Shanghai • Taipei • New York • Verona • London • Paris GTX1850K, GTX2450K 050531 ED6 JJ...
-
Page 2: Table Of Contents
Unpacking Fitting and removing the battery pack Battery charging To obtain the best life for the battery Battery indicator LED Work area light Using the drill Forward/reverse switch Adjustable torque Drilling positions Torque adjustment/hammer selection collar 2 Speed gearbox Inserting and removing bits... -
Page 3: Description Of Symbols
Wear hearing protection. Wear eye protection. Wear breathing protection. Double insulated for additional protection. Conforms to relevant standards for electromagnetic compatibility. Specifications GTX1850K Nominal battery charge: 18V Charger: 230-240V ~ 50Hz Batteries: 2 x 1.5Ah Charging time: 3-5 Hours Drill no... -
Page 4: Safety Instructions
Safety instructions WARNING. Read and understand all instructions. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. The term “power tool” in all of the warnings below refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool. -
Page 5: Additional Safety Instructions For Drills
Ensure that the lighting is adequate. • Do not put pressure on the drill, such that it slows the motor down. Allow the drill bit to cut without pressure. You will get better results and you will be taking better care of your tool. -
Page 6: Additional Safety Instructions For The Charger
If in doubt, do not plug in the tool. Using a power source with a voltage less than the nameplate rating is harmful to the motor. The tool must be used only for its prescribed purpose. Any use other than those mentioned in this Manual will be considered a case of misuse. -
Page 7: Additional Safety Instructions For The Battery Pack
• Do not store or use the tool and battery pack in locations where the temperature may reach or exceed 104°F (40°C) such as alongside sheds or metal structures in the summer. • The charger is designed for use from a standard household electrical supply (230–240 volts). -
Page 8: Know Your Product
Know your product This drill is mainly used for drilling in wood or metal sheet and screwdriving. Use the tool and accessories only for intended applications. All other applications are expressly ruled out. 1. Keyless chuck 2. Torque adjustment/hammer selection collar 3. -
Page 9: Unpacking
Failure to do so could result in serious personal injury. Fitting and removing the battery pack To remove the battery pack from the drill firmly press the battery release tabs (7) at either side of the battery pack, and slide the battery backward out of the tool. -
Page 10: Led Work Area Light
The range of nineteen torque settings allows better control when using the drill as a screwdriver as it prevents over- tightening of the screws. The symbols circling the collar are used to indicate the level of torque. -
Page 11: Inserting And Removing Bits
Inserting and removing bits The drill is fitted with auto spindle lock which means if you try and rotate the chuck by hand the spindle of the drill will automatically lock. This means you only need to grasp the chuck and rotate the chuck housing to remove or fit accessories. -
Page 12: Chuck Replacement
Always wear eye protection. Turn the torque adjustment collar/hammer selection collar (2) to the “drill” position and low gear, on the gear selector (14). Tighten the chuck around the shorter end of a hex key (not supplied) of 5mm or greater size. Using a wooden mallet or similar object, strike the longer end in the clockwise direction. - Page 16 Carefully read the entire Instruction Manual Before returning this product for a Warranty Claim or any other reason Please Call 1300 880 001 (Australia) or 0800 445 721 (New Zealand) When you make your call, please have the following information at hand: •...
