Digital Multimedia Projector
PalmPro 7763PA/65PA
User's Guide
Thank you very much for purchasing this Benq DLP™ Technology Projector.
Please read this operating guide to ensure correct use of the device. After reading this manual, keep it
for future reference.
Outline
This DLP™ Technology Projector can display various
computer signals and NTSC/PAL/SECAM video signals.
Features
(1)
High brightness
(2)
High resolution
(3)
Compact size, light weight for portability
(4)
RGB input terminal
(5)
RS232 Communication
(6)
Mouse emulation
(7)
Complies with VESA DDC1/2B specifications
English I
Advertisement
Table of Contents
Related Manuals for BenQ PALMPRO 7765PA
Summary of Contents for BenQ PALMPRO 7765PA
- Page 1 Digital Multimedia Projector PalmPro 7763PA/65PA User’s Guide Thank you very much for purchasing this Benq DLP™ Technology Projector. Please read this operating guide to ensure correct use of the device. After reading this manual, keep it for future reference. Outline This DLP™...
-
Page 2: Monitor Information
Copyright Copyright © 2002 by Benq Corporation. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission of this company. -
Page 3: Table Of Contents
Table of Contents Introduction....................................... 1 Projector Features ..................................1 Description ..................................... 2 FRONT ..................................2 REAR ..................................2 BOTTOM .................................. 3 Installation....................................... 3 Positioning ................................. 3 Adjustable Feet................................. 3 Moving the Projector..................................4 Accessories ..................................... 5 Connection ................................6 Connecting the Projector to Computer/Notebook ..................6 Connecting the Projector to Macintosh/Power Book.................. -
Page 5: Introduction
Introduction Projector Features A. Image Resolution Fully compatible with true SVGA(63PA)/XGA(65PA), and supports SXGA using advanced intelligent compression technology. The advanced intelligent compression technology enables it to present clear compression SVGA/XGA images without line omission. B. Brightness Provides superior brightness using TI’s Digital Micromirror Device (DMD) and our own optical design, with a geometric effect that increases light usage efficiency. -
Page 6: Description
NTSC U.S. and Canada standard Western Europe standard SECAM France and Eastern Europe standard NTSC4.43 Middle East standard If users want to watch CATV, AV box will serve the need. Description A. FRONT Figure 1 Front view B. REAR Figure 2 Rear view English 2... -
Page 7: Bottom
C. BOTTOM Figure 3 Bottom view Installation A. Positioning This projector is basically designed to project on a flat projection surface. It can focus from 1.5m– 14m and adjust the screen size like figure below. Figure 4 Positioning B. Adjustable Feet Picture tilt and projection angle can be adjusted by twisting Adjustable Feet. -
Page 8: Moving The Projector
Moving the Projector Use the carrying handle when moving the projector. Replace the lens cover and rotate the feet fully clockwise (to shorten the feet) when moving the projector to prevent damage to the projector. Caution The carry bag (supplied) is intended to protect the projector from dust and scratches on the surface of the cabinet. -
Page 9: Accessories
Accessories Please check and make sure your box contains everything listed below. If any pieces are missing, contact your dealer. Please save the original box and packing materials in case you ever need to ship the unit. Projection Lens Remote Control User's manual AAA Batteries Mac Adapter... -
Page 10: Connection
Connection A. Connecting the Projector to Computer/Notebook Figure 8 Connection to PC Figure 9 Connection to notebook English 6... -
Page 11: Connecting The Projector To Macintosh/Power Book
B. Connecting the Projector to Macintosh/Power Book Figure 10 Connection to Macintosh Figure 11 Connection to Power Book English 7... -
Page 12: Operation
Operation Turn On/Off Procedure A. Power on Press the Standby/On key to turn on the lamp. The LED will blink green during warm up and then light solid green. "INPUT SIGNAL DETECTED, ACTIVATING AUTO IMAGE" will be displayed on the screen after the projector has identified the input signal;... - Page 13 MAIN UNIT FUNCTION AUTO To correct the size and phase of the projected image automatically. KEYSTONE + To correct the upper distortion of the projected image when keystone occurs. To correct the lower distortion of the projected image KEYSTONE - when keystone occurs.
-
Page 14: Remote Control
B. Remote Control (LED) Stand by /on Laser Source Menu Exit -Keystone+ Blank Freeze R-Click L-Click Drag Volume Magnify Return Mute Reverse Channel down Channel up Add/Erase scan Scan Figure 14 Remote control English 10... - Page 15 Main Unit Function Standby/On To turn the projection lamp on and off. Freeze Pressing this button displays a still (frozen) picture. Magnify Pressing this button partially magnifies a displayed picture. (Move the picture with the Disk Pad after pressing the Magnify button.) When the OSD menu is active, Disk Pad acts as 56selecting device.
-
Page 16: Usage And Replacement Of Lamp
Figure 15 Battery replacement process Remote Control Range The remote sensors are located on the back of the unit. It can function in a range 50 degrees horizontal and 30 degrees vertical relative to a line that is a right angle to the remote sensor. The distance between the remote control and remote sensor must be shorter than four meters (13 feet). - Page 17 “PLEASE CHANGE A NEW LAMP. THE POWER WILL TURN OFF AFTER 20 HOURS” will be displayed on the screen if the lamp has been operated for 1480 hours. The “20” will count down (see figure 18). Figure 18 Lamp replacement warning signal Ⅱ...
-
Page 18: Replacing The Lamp
B. Replacing the Lamp Replacing the lamp When replacing the lamp, turn off the projector and unplug the AC cord. Wait 45 minutes so that the lamp can cool. High-pressure lamp when hit, may explode if improperly handled. Caution: Dispose of used lamps in accordance with local authorities. As the lamp is made of glass, do not apply shocks to it or scratch it. - Page 19 Lamp Replacement Procedure Step 1 Step 2 Step 3 Lamp replacement Figure 20 : Step 1, Step 2, Step 3 English 15...
-
Page 20: Osd
Resetting Lamp Timer If replacing the lamp after 1500 hours of operation, please carry out the following operation within 10 minutes of powering on. FUNCTION Press the MENU button into OSD menu, and “4” (KEYSTONE+) “3” (KEYSTONE-) to select the Control page. Then press the Menu button again to highlight the Lamp item. -
Page 21: Display Page
Input status PC input without AV box PC input with AV box Video input with AV box Subpage Display Display Display Image Image Image Control Control Control Source Source A. Display Page When a PC is the input source, there will be only four items on this page: Keystone, Brightness, Contrast, and Color Balance (Fig. - Page 22 Figure 24 Image sub-page…. Only available when Figure 25 Image sub-page – Only available when the the input signal is PC input signal is from video, S-video, TV or CATV Setting effects When Auto Resize is on, the projector determines the best fit of the image to the Auto screen.
-
Page 23: Control Page
C. Control Page When users go into the Control sub-page, the first item “Auto” will be highlighted. There are five items on this page: Reset, Language, Mirror, Auto Off and Reset (Fig. 26). Figure 26 Control sub-page Setting effects To reset display, image and control settings to factory settings. Auto Language To select the OSD menu language. -
Page 24: Other Correspondent Remote Functions And Messages
Other Correspondent Remote Functions and Messages FUNCTION The selected source will be displayed at the bottom right of the screen for 3 seconds after selecting the source. (PC, VIDEO, S-VIDEO). Source The image will be frozen when the “Freeze” button is pressed. -
Page 25: Maintenance And Troubleshooting
Maintenance and Troubleshooting A. Lamp Replacement Refer to Page 17 B. Cleaning the Lens Follow these steps to clean the projection lens: 1. Apply a non-abrasive camera lens cleaner to a soft, dry cleaning cloth (abrasive cleaners, solvents or other harsh chemicals might scratch the lens). 2. -
Page 26: Specifications
Specifications A. Optical 1-chip 0.7” DMD (Digital Micromirror Device) Lens Manual zoom, manual focus (F=2.8 to 3.1 f=31 to 40) Lamp mercury lamp 150W 25” to 300” Image size Projection Distance 1.5 to 14 M 450:1 Contrast Ratio B. Electrical Inputs RGB (H:31.47 to 68.70 kHz V:56.25 to 85.00 Hz) Video... -
Page 27: Av Connection Port
For S-Video Input *AV box is sold separately and is not included in the standard configuration of accessories in the unit. Please contact the dealer nearest you need the box or visit the Benq Corporation web site for more information. -
Page 28: Connecting The Box
Connecting the Box Please follow the instructions here to place the AV box: Figure 30 Side View of AV box Figure 29 Bottom View of AV box To attach the AV box to the unit： 1. Precisely place the two chocks at the lower surface of the AV box into the lower slots in the correspondent position in the projector.
