OWNER'S MANUAL
XVS1300A
11C-28199-E1

Advertisement

Table of Contents
loading

Related Manuals for Yamaha Midnight Star XVS1300A

Summary of Contents for Yamaha Midnight Star XVS1300A

  • Page 1 OWNER’S MANUAL XVS1300A 11C-28199-E1...
  • Page 2 EAU26944 DECLARATION of CONFORMITY Company: YAMAHA MOTOR ELECTRONICS CO., LTD. Address: 1450-6, Mori, Mori-Machi, Shuchi-gun, Shizuoka-Ken, 437-0292 Japan Hereby declare that the product: Kind of equipment: IMMOBILIZER Type-designation: 5SL-00 is in compliance with following norm(s) or documents: R&TTE Directive(1999/5/EC) EN300 330-2 v1.1.1(2001-6), EN60950-1(2001)
  • Page 3 Yamaha a reputation for dependability. Please take the time to read this manual thoroughly, so as to enjoy all advantages of your XVS1300A. The owner’s manual does not only instruct you in how to operate, inspect and maintain your motorcycle, but also in how to safeguard yourself and others from trouble and injury.

  • Page 4: Important Manual Information

    This manual should be considered a permanent part of this motorcycle and should remain with it even if the motorcycle is subsequently sold. Yamaha continually seeks advancements in product design and quality. Therefore, while this manual contains the most current product information available at the time of printing, there may be minor discrepancies between your motorcycle and this manual.
  • Page 5 IMPORTANT MANUAL INFORMATION EAU10200 XVS1300A OWNER’S MANUAL ©2007 by Yamaha Motor Co., Ltd. 1st edition, August 2007 All rights reserved. Any reprinting or unauthorized use without the written permission of Yamaha Motor Co., Ltd. is expressly prohibited. Printed in Japan.

  • Page 6: Table Of Contents

    TABLE OF CONTENTS SAFETY INFORMATION ....1-1 PRE-OPERATION CHECKS ..... 4-1 Adjusting the brake lever free Pre-operation check list ....4-2 play ........... 6-17 DESCRIPTION ........2-1 Adjusting the rear brake light Left view ..........2-1 OPERATION AND IMPORTANT switch ........6-17 Right view ........2-2 RIDING POINTS.........
  • Page 7 TABLE OF CONTENTS Replacing a turn signal light bulb ...........6-30 Replacing the license plate light bulb ...........6-30 Replacing the auxiliary light bulb ...........6-31 Supporting the motorcycle ....6-32 Troubleshooting ......6-33 Troubleshooting charts ....6-34 MOTORCYCLE CARE AND STORAGE ..........7-1 Matte color caution ......7-1 Care ..........7-1 Storage ...........7-3 SPECIFICATIONS ......8-1...

  • Page 8: Safety Information

    SAFETY INFORMATION EAU10281 AND/OR WHEN MADE NECES- • Ride where other motorists can SARY BY MECHANICAL CONDI- see you. Avoid riding in another MOTORCYCLES SINGLE TIONS. motorist’s blind spot. TRACK VEHICLES. THEIR SAFE USE Many accidents involve inexperi- AND OPERATION ARE DEPENDENT Safe riding enced operators.
  • Page 9 Modifications made to this motorcycle other motorists can see you. the single most critical factor in the pre- not approved by Yamaha, or the re- The posture of the operator and vention or reduction of head injuries. moval of original equipment, may ren- passenger is important for proper Always wear an approved helmet.
  • Page 10 Maximum load: been specifically designed for use on create instability due to improper 210 kg (463 lb) this motorcycle. Since Yamaha cannot weight distribution or aerody- test all other accessories that may be namic changes. If accessories When loading within this weight limit,...
  • Page 11 SAFETY INFORMATION tor and may limit control ability, Always turn the engine off before or clothing, immediately wash the therefore, such accessories are leaving the motorcycle unattended affected area with soap and water not recommended. and remove the key from the main and change your clothes.

  • Page 12: Description

    DESCRIPTION EAU10410 Left view 1. Front turn signal light (page 6-30) 9. Rear turn signal light (page 6-30) 2. Headlight (page 6-28) 10.Engine oil level check window (page 6-8) 3. Seat lock (page 3-15) 11.Shift pedal (page 3-11) 4. Fuel injection system fuse (page 6-26) 12.Engine oil filler cap (page 6-8) 5.

  • Page 13: Right View

    DESCRIPTION EAU10420 Right view 1. Tail/brake light (page 6-30) 9. Rear brake light switch (page 6-17) 2. Rear brake fluid reservoir (page 6-18) 10.Engine oil filter cartridge (page 6-8) 3. Owner’s tool kit (page 6-1) 11.Engine oil drain bolt (page 6-8) 4.

  • Page 14: Controls And Instruments

    DESCRIPTION EAU10430 Controls and instruments 1. Clutch lever (page 3-11) 2. Left handlebar switches (page 3-9) 3. Multi-function meter unit (page 3-6) 4. Main switch/steering lock (page 3-2) 5. Right handlebar switches (page 3-9) 6. Throttle grip (page 6-13) 7. Brake lever (page 3-12)

  • Page 15: Instrument And Control Functions

    Do not expose any key to exces- a Yamaha dealer to have them re-reg- sively high temperatures. istered. Do not use the key with the red Do not place any key close to bow for driving.

  • Page 16: Main Switch/Steering Lock

    INSTRUMENT AND CONTROL FUNCTIONS Keep other immobilizer system EAU10471 EAU38530 Main switch/steering lock keys away from the main switch All electrical circuits are supplied with as they may cause signal inter- power; the meter lighting, taillight, li- ference. cense plate light and auxiliary light come on, and the engine can be start- ed.
  • Page 17 INSTRUMENT AND CONTROL FUNCTIONS To lock the steering To unlock the steering EAU34341 (Parking) The steering is locked, and the taillight, license plate light and auxiliary light are on. The hazard lights and turn signal lights can be turned on, but all other electrical systems are off.

  • Page 18: Indicator And Warning Lights

    NOTE: 7. Fuel level warning light “ ” have a Yamaha dealer check the elec- 8. Immobilizer system indicator light Even if the oil level is sufficient, the trical circuit. warning light may flicker when...
  • Page 19 Yamaha dealer check the self-diagno- for 3.0 seconds. If this occurs, system. (See page 3-8 for an explana- sis system. (See page 3-8 for an expla- have a Yamaha dealer check the tion of the self-diagnosis device.) nation of the self-diagnosis device.) vehicle.

  • Page 20: Multi-Function Meter Unit

    INSTRUMENT AND CONTROL FUNCTIONS EAU42901 a fuel reserve tripmeter (which Speedometer Multi-function meter unit shows the distance traveled on the fuel reserve) a clock a self-diagnosis device a brightness control mode NOTE: Be sure to turn the key to “ON” before using the “SELECT”...
  • Page 21 INSTRUMENT AND CONTROL FUNCTIONS Odometer, tripmeters, fuel reserve Push the “RESET” switch for less tomatically, and the display will return tripmeter and clock than one second to display the to the prior mode after refueling and clock for five seconds, regardless traveling 5 km (3 mi).
  • Page 22 Yamaha suit the outside lighting conditions. dealer check the vehicle. NOTE: To set the brightness If the display indicates error code 52, 1.

  • Page 23: Anti-Theft Alarm (Optional)

    “SELECT” switch after This model can be equipped with an five seconds or more. Left optional anti-theft alarm by a Yamaha 4. Push the “ ” or “ ” side of the dealer. Contact a Yamaha dealer for “SELECT”...
  • Page 24 INSTRUMENT AND CONTROL FUNCTIONS Right position. To cancel the turn signal EAU12733 Hazard switch “ ” lights, push the switch in after it has re- With the key in the “ON” or “ ” posi- turned to the center position. tion, use this switch to turn on the haz- ard lights (simultaneous flashing of all EAU12500...

  • Page 25: Clutch Lever

    INSTRUMENT AND CONTROL FUNCTIONS EAU42531 EAU12820 EAU12880 “RESET” switch Clutch lever Shift pedal This switch is used to perform selec- tions in the odometer, tripmeter and clock mode of the multi-function meter unit. See “Multi-function meter unit” on page 3-6 for detailed information. 1.

  • Page 26: Brake Lever

    INSTRUMENT AND CONTROL FUNCTIONS EAU12890 EAU12941 EAU13090 Brake lever Brake pedal Fuel tank cap 1. Brake lever 1. Brake pedal 1. Fuel tank cap lock cover 2. Unlock. The brake lever is located at the right The brake pedal is on the right side of handlebar grip.

  • Page 27: Fuel

    Avoid spilling fuel on the hot en- as well as to the exhaust system. gine. Your Yamaha engine has been de- signed to use regular unleaded gaso- line with a research octane number of 91 or higher. If knocking (or pinging) oc-...

  • Page 28: Fuel Tank Breather Hose

    INSTRUMENT AND CONTROL FUNCTIONS curs, use a gasoline of a different brand EAU13412 EAU13431 Fuel tank breather hose Catalytic converter or premium unleaded fuel. Use of un- This model is equipped with a catalytic leaded fuel will extend spark plug life converter in the exhaust system.

  • Page 29: Rider Seat

    INSTRUMENT AND CONTROL FUNCTIONS EAU42750 EAU14320 Rider seat Helmet holder To remove the rider seat 1. Insert the key into the seat lock, and then turn it counterclockwise. 1. Projection 2. Seat holder 1. Helmet holder 2. Push the front of the seat down to The helmet holder is located under the lock it in place.

  • Page 30: Adjusting The Shock Absorber Assembly

    EWA10220 ence. WARNING It is recommended to have a Yamaha This shock absorber contains highly dealer adjust the spring preload. pressurized nitrogen gas. For prop- ECA10100...

  • Page 31: Sidestand

    INSTRUMENT AND CONTROL FUNCTIONS sponsible for property damage or EAU15301 below and have a Yamaha dealer re- Sidestand personal injury that may result from pair it if it does not function proper- The sidestand is located on the left side improper handling.

  • Page 32: Ignition Circuit Cut-Off System

    Periodically check the operation of the ignition circuit cut-off system according to the following procedure. EWA10250 WARNING If a malfunction is noted, have a Yamaha dealer check the system be- fore riding. 3-18...
  • Page 33 5. Push the start switch. Does the engine start? The neutral switch may be defective. The motorcycle should not be ridden until checked by a Yamaha dealer. With the engine still running: 6. Move the sidestand up. 7. Keep the clutch lever pulled.

  • Page 34: Pre-Operation Checks

    PRE-OPERATION CHECKS EAU15593 The condition of a vehicle is the owner’s responsibility. Vital components can start to deteriorate quickly and unexpectedly, even if the vehicle remains unused (for example, as a result of exposure to the elements). Any damage, fluid leakage or loss of tire air pressure could have serious consequences.

  • Page 35: Pre-Operation Check List

    • If necessary, add recommended coolant to specified level. 6-11 • Check cooling system for leakage. • Check operation. • If soft or spongy, have Yamaha dealer bleed hydraulic system. • Check lever free play. • Adjust if necessary. Front brake •...
  • Page 36 • Make sure that operation is smooth. • Check cable free play. Throttle grip 6-13, 6-21 • If necessary, have Yamaha dealer adjust cable free play and lubricate cable and grip housing. • Make sure that operation is smooth. Control cables 6-20 •...

  • Page 37: Operation And Important Riding Points

    3-18. Yamaha dealer check the electrical cir- short time. Always make sure Never ride with the sidestand cuit. that there is adequate ventila- down.

  • Page 38: Shifting

    OPERATION AND IMPORTANT RIDING POINTS serve the battery. Do not crank the en- EAU16671 ECA10260 Shifting CAUTION: gine more than 10 seconds on any one attempt. Even with the transmission in the neutral position, do not ECA11130 coast for long periods of time CAUTION: with the engine off, and do not For maximum engine life, always...

  • Page 39: Tips For Reducing Fuel Consumption

    (e.g., in traffic jams, at traffic immediately have a Yamaha dealer result in engine overheating must be lights or at railroad crossings). check the vehicle.

  • Page 40: Parking

    OPERATION AND IMPORTANT RIDING POINTS EAU17212 Parking When parking, stop the engine, and then remove the key from the main switch. EWA10310 WARNING Since the engine and exhaust system can become very hot, park in a place where pedestri- ans or children are not likely to touch them.

  • Page 41: Periodic Maintenance And Minor Repair

    If you are not familiar with mainte- certain maintenance work correctly. nance work, have a Yamaha dealer do it for you. NOTE: If you do not have the tools or experi- ence required for a particular job, have a Yamaha dealer perform it for you.

  • Page 42: Periodic Maintenance And Lubrication Chart

    From 50000 km (30000 mi), repeat the maintenance intervals starting from 10000 km (6000 mi). Items marked with an asterisk should be performed by a Yamaha dealer as they require special tools, data and technical skills.
  • Page 43 PERIODIC MAINTENANCE AND MINOR REPAIR ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 10000 km 20000 km 30000 km 40000 km CHECK (600 mi) (6000 mi) (12000 mi) (18000 mi) (24000 mi) √ √ √ √ √ • Check for cracks or damage. 8 * Brake hoses •...
  • Page 44 PERIODIC MAINTENANCE AND MINOR REPAIR ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 10000 km 20000 km 30000 km 40000 km CHECK (600 mi) (6000 mi) (12000 mi) (18000 mi) (24000 mi) Clutch lever pivot • Lubricate with lithium-soap-based √...
  • Page 45 PERIODIC MAINTENANCE AND MINOR REPAIR ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 10000 km 20000 km 30000 km 40000 km CHECK (600 mi) (6000 mi) (12000 mi) (18000 mi) (24000 mi) Moving parts and √ √ √ √...

  • Page 46: Removing And Installing The Panel

    PERIODIC MAINTENANCE AND MINOR REPAIR EAU18751 EAU42430 Removing and installing the Checking the spark plugs panel The spark plugs are important engine components, which are easy to check. The panel shown needs to be removed Since heat and deposits will cause any to perform some of the maintenance spark plug to slowly erode, the spark jobs described in this chapter.
  • Page 47 3. Remove the spark plug as shown, diagnose such problems yourself. In- Spark plug gap: with the spark plug wrench includ- stead, have a Yamaha dealer check 0.8–0.9 mm (0.031–0.035 in) ed in the additional tool kit, which the vehicle.

  • Page 48: Engine Oil And Oil Filter Cartridge

    PERIODIC MAINTENANCE AND MINOR REPAIR EAU42593 2. Start the engine, warm it up for Engine oil and oil filter car- NOTE: several minutes, and then turn it The engine oil should be between the tridge off. minimum and maximum level marks. The engine oil level should be checked 3.
  • Page 49 Make sure that the O-ring is properly 17 Nm (1.7 m·kgf, 12 ft·lbf) An oil filter wrench is available at a seated. Yamaha dealer. 8. Install the engine oil drain bolt, and 7. Install the new oil filter cartridge then tighten it to the specified 6.
  • Page 50 CAUTION: “ENERGY CONSERVING II” or If the oil level warning light flickers higher. or remains on, immediately turn the Make sure that no foreign mate- engine off and have a Yamaha dealer rial enters the crankcase. check the vehicle. 6-10...

  • Page 51: Coolant

    PERIODIC MAINTENANCE AND MINOR REPAIR EAU20070 Coolant The coolant level should be checked before each ride. In addition, the cool- ant must be changed at the intervals specified in the periodic maintenance and lubrication chart. EAU42630 To check the coolant level 1.

  • Page 52: Replacing The Air Filter Element

    PERIODIC MAINTENANCE AND MINOR REPAIR If water has been added to the EAU42441 Replacing the air filter element coolant, have a Yamaha dealer The air filter element should be re- check the antifreeze content of placed at the intervals specified in the...

  • Page 53: Checking The Throttle Cable Free Play

    The valve clearance changes with use, resulting in improper air-fuel mixture and/or engine noise. To prevent this from occurring, the valve clearance must be adjusted by a Yamaha dealer at the intervals specified in the periodic maintenance and lubrication chart. 1. Air filter element 3.

  • Page 54: Tires

    PERIODIC MAINTENANCE AND MINOR REPAIR EAU21561 passenger, cargo, and accesso- Tire air pressure (measured on cold Tires ries does not exceed the speci- tires): To maximize the performance, durabil- fied maximum load for the 0–90 kg (0–198 lb): ity, and safe operation of your motor- Front: vehicle.
  • Page 55 If the center tread depth reaches the specified limit, if the tire has a nail or Front tire: glass fragments in it, or if the sidewall is Size: cracked, have a Yamaha dealer re- 130/90 16M/C 67H place the tire immediately. Manufacturer/model: DUNLOP/D404F X...

  • Page 56: Cast Wheels

    If any damage is 5. Loosen the locknut further down found, have a Yamaha dealer re- the clutch cable. place the wheel. Do not attempt even the smallest repair to the wheel.

  • Page 57: Adjusting The Brake Lever Free Play

    A soft or spongy feeling in the brake lever can indicate the presence of air in the hydraulic system. If there is air in the hy- draulic system, have a Yamaha dealer bleed the system before operating the motorcycle. Air in 1. Locknut 1.

  • Page 58: Checking The Front And Rear Brake Pads

    EAU22580 Checking the front and rear Checking the brake fluid level peared, have a Yamaha dealer replace brake pads the brake pads as a set. Front brake The front and rear brake pads must be...

  • Page 59: Changing The Brake Fluid

    Changing the brake fluid is above the minimum level mark and ter the brake fluid reservoir when Have a Yamaha dealer change the replenish if necessary. A low brake fluid refilling. Water will significantly brake fluid at the intervals specified in...

  • Page 60: Drive Belt Slack

    To check the drive belt slack or does not move smoothly, have a 1. Place the vehicle on the sidestand. Yamaha dealer check or replace it. 2. Note the current position of the drive belt using the marks near the Recommended lubricant: drive belt check hole.

  • Page 61: Checking And Lubricating The Throttle Grip And Cable

    PERIODIC MAINTENANCE AND MINOR REPAIR EAU23111 EAU44271 Recommended lubricant: Checking and lubricating the Checking and lubricating the Lithium-soap-based grease throttle grip and cable brake and shift pedals The operation of the throttle grip should be checked before each ride. In addi- tion, the cable should be lubricated at the intervals specified in the periodic maintenance chart.

  • Page 62: Checking And Lubricating The Brake And Clutch Levers

    EWA10730 WARNING If the sidestand does not move up and down smoothly, have a Yamaha dealer check or repair it. Recommended lubricant: The operation of the brake and clutch Lithium-soap-based grease levers should be checked before each ride, and the lever pivots should be lu- bricated if necessary.

  • Page 63: Lubricating The Swingarm Pivots

    PERIODIC MAINTENANCE AND MINOR REPAIR EAUM1650 EAU23250 EAU23271 Lubricating the swingarm piv- Lubricating the rear suspen- Checking the front fork sion The condition and operation of the front fork must be checked as follows at the intervals specified in the periodic main- tenance and lubrication chart.

  • Page 64: Checking The Steering

    Securely support the vehicle so that fork does not operate smoothly, there is no danger of it falling over. have a Yamaha dealer check or re- pair it. 2. Hold the lower ends of the front fork legs and try to move them for- ward and backward.

  • Page 65: Checking The Wheel Bearings

    If there is play in the wheel burns. Avoid any contact with hub or if the wheel does not turn skin, eyes or clothing and al- smoothly, have a Yamaha dealer check ways shield your eyes when the wheel bearings. working near batteries. In case of contact, administer the fol- lowing FIRST AID.

  • Page 66: Replacing The Fuses

    To charge the battery located under the rider seat. (See page battery damage. Have a Yamaha dealer charge the bat- 3-15.) To charge a sealed-type (MF) tery as soon as possible if it seems to If a fuse is blown, replace it as follows.
  • Page 67 4. Turn the key to “ON” and turn on the electrical circuit in question to check if the device operates. 5. If the fuse immediately blows again, have a Yamaha dealer check the electrical system. 6-27...

  • Page 68: Replacing The Headlight Bulb

    PERIODIC MAINTENANCE AND MINOR REPAIR 6. Install the battery cover, and then EAU42890 Replacing the headlight bulb hook the battery band onto the This model is equipped with a quartz holder. bulb headlight. If the headlight bulb burns out, replace it as follows. 1.
  • Page 69 Thoroughly clean off any dirt and fingerprints on the headlight bulb using a cloth moistened with al- cohol or thinner. 1. Headlight bulb holder 9. Have a Yamaha dealer adjust the 2. Headlight bulb headlight beam if necessary. EWA10790 WARNING Headlight bulbs get very hot.

  • Page 70: Replacing The Tail/Brake Light Bulb

    PERIODIC MAINTENANCE AND MINOR REPAIR EAU24131 EAU24210 EAU42482 Replacing the tail/brake light Replacing a turn signal light Replacing the license plate bulb bulb light bulb 1. Remove the tail/brake light lens by 1. Remove the turn signal lens by re- 1.

  • Page 71: Replacing The Auxiliary Light Bulb

    PERIODIC MAINTENANCE AND MINOR REPAIR 3. Remove the license plate light 6. Install the socket (together with the EAU42870 Replacing the auxiliary light socket (together with the bulb) by bulb) by pushing it in and turning it bulb turning it counterclockwise, and clockwise until it stops.

  • Page 72: Supporting The Motorcycle

    PERIODIC MAINTENANCE AND MINOR REPAIR EAU24350 a jack either under each side of the Supporting the motorcycle frame in front of the rear wheel or under Since this model is not equipped with a each side of the swingarm. centerstand, follow these precautions when removing the front and rear wheel or performing other maintenance requiring the motorcycle to stand up-...

  • Page 73: Troubleshooting

    The following troubleshooting charts represent quick and easy procedures for checking these vital systems your- self. However, should your motorcycle require any repair, take it to a Yamaha dealer, whose skilled technicians have the necessary tools, experience, and know-how to service the motorcycle properly.

  • Page 74: Troubleshooting Charts

    Remove the spark plugs and check the electrodes. The engine does not start. Have a Yamaha dealer check the vehicle. Check the battery. 4. Battery The engine turns over The battery is good.
  • Page 75 Start the engine. If the engine overheats again, have a The coolant level Yamaha dealer check and repair the cooling system. is OK. NOTE: If coolant is not available, tap water can be temporarily used instead, provided that it is changed to the recommended coolant as soon as possible.

  • Page 76: Motorcycle Care And Storage

    Rust and corrosion can develop matte colored finished parts. Be Cleaning even if high-quality components are sure to consult a Yamaha dealer for ECA10771 advice on what products to use be- used. A rusty exhaust pipe may go un- CAUTION: fore cleaning the vehicle.
  • Page 77 MOTORCYCLE CARE AND STORAGE contact with strong or abrasive scratched, use a quality plastic 1. Clean the motorcycle with cold wa- cleaning products, solvent or polishing compound after ter and a mild detergent, after the thinner, fuel (gasoline), rust re- washing.

  • Page 78: Storage

    Make sure that there is no oil or NOTE: wax on the brakes or tires. Consult a Yamaha dealer for advice on If necessary, clean the brake Long-term what products to use. discs and brake linings with a...
  • Page 79 MOTORCYCLE CARE AND STORAGE 3. Perform the following steps to pro- 4. Lubricate all control cables and the tect the cylinders, piston rings, etc. pivoting points of all levers and from corrosion. pedals as well as of the side- a. Remove the spark plug caps stand/centerstand.

  • Page 80: Specifications

    SPECIFICATIONS Dimensions: Engine oil: Spark plug (s): Overall length: Type: Manufacturer/model: 2490 mm (98.0 in) SAE 20W-40 NGK/LMAR7A-9 Overall width: Recommended engine oil grade: Spark plug gap: 980 mm (38.6 in) API service SG type or higher, JASO 0.8–0.9 mm (0.031–0.035 in) Overall height: standard MA Clutch:...
  • Page 81 SPECIFICATIONS Chassis: Front: Front suspension: 250 kPa (36 psi) (2.50 kgf/cm²) Frame type: Type: Rear: Double cradle Telescopic fork 280 kPa (41 psi) (2.80 kgf/cm²) Caster angle: Spring/shock absorber type: Loading condition: 32.70 ° Coil spring/oil damper 90–210 kg (198–463 lb) Trail: Wheel travel: Front:...
  • Page 82 SPECIFICATIONS Rear turn signal light: Parking lighting fuse: 12 V, 21.0 W × 2 10.0 A Auxiliary light: Radiator fan fuse: 12 V, 5.0 W × 1 20.0 A License plate light: Fuel injection system fuse: 12 V, 5.0 W × 1 10.0 A Meter lighting: Backup fuse:...

  • Page 83: Consumer Information

    Record the key identification number, vehicle identification number and mod- el label information in the spaces pro- vided below for assistance when ordering spare parts from a Yamaha dealer or for reference in case the vehi- cle is stolen. KEY IDENTIFICATION NUMBER: 1.
  • Page 84 1. Model label The model label is affixed to the frame under the rider seat. (See page 3-15.) Record the information on this label in the space provided. This information will be needed when ordering spare parts from a Yamaha dealer.
  • Page 85 INDEX Fuel ............3-13 Parking............ 5-4 Fuel consumption, tips for reducing ..5-3 Part locations .......... 2-1 Air filter element, replacing ....6-12 Fuel level warning light......3-4 Pass switch........... 3-10 Anti-theft alarm (optional) ....... 3-9 Fuel tank breather hose ......3-14 Periodic maintenance and Auxiliary light bulb, replacing ....
  • Page 86 INDEX Troubleshooting ........6-33 Troubleshooting charts ......6-34 Turn signal indicator light ......3-4 Turn signal light bulb, replacing .... 6-30 Turn signal switch ......... 3-10 Valve clearance ........6-13 Vehicle identification number ....9-1 Wheel bearings, checking..... 6-25 Wheels ..........6-16...
  • Page 88 YAMAHA MOTOR CO., LTD. PRINTED ON RECYCLED PAPER PRINTED IN JAPAN 2007.10-0.3×1 CR...
