OWNER'S MANUAL
XVS13AW(C)
LIT-11626-20-42
3D8-28199-10

Advertisement

Table of Contents
loading

Summary of Contents for Yamaha XVS13AW(C)

  • Page 1 OWNER’S MANUAL XVS13AW(C) LIT-11626-20-42 3D8-28199-10...
  • Page 2 EAU10041...
  • Page 3 Yamaha has met these standards without reducing the performance or economy of operation of the motorcycle. To maintain these high standards, it is important that you and your Yamaha dealer pay close attention to the recommended maintenance schedules and operating instructions contained within this manual.
  • Page 4: Important Manual Information

    This manual should be considered a permanent part of this motorcycle and should remain with it even if the motorcycle is subsequently sold. Yamaha continually seeks advancements in product design and quality. Therefore, while this manual contains the most current product information available at the time of printing, there may be minor discrepancies between your motorcycle and this manual.
  • Page 5 IMPORTANT MANUAL INFORMATION AND UNTIL YOU HAVE BEEN TRAINED IN SAFE AND PROPER RIDING TECHNIQUES. REGULAR INSPECTIONS AND CAREFUL MAINTENANCE, ALONG WITH GOOD RIDING SKILLS, WILL ENSURE THAT YOU SAFELY ENJOY THE CAPABILITIES AND THE RELIABILITY OF THIS MOTORCYCLE. *Product and specifications are subject to change without notice.
  • Page 6 IMPORTANT MANUAL INFORMATION EAU10192 AFFIX DEALER LABEL HERE XVS13AW(C) OWNER’S MANUAL ©2006 by Yamaha Motor Corporation, U.S.A. 1st edition, July 2006 All rights reserved. Any reprinting or unauthorized use without the written permission of Yamaha Motor Corporation, U.S.A. is expressly prohibited.
  • Page 7: Table Of Contents

    SAFETY INFORMATION ...1-1 Location of important labels ...1-5 DESCRIPTION ...2-1 Left view ...2-1 Right view ...2-2 Controls and instruments ...2-3 INSTRUMENT AND CONTROL FUNCTIONS ...3-1 Main switch/steering lock ...3-1 Indicator and warning lights ...3-2 Multi-function meter unit ...3-3 Handlebar switches ...3-6 Clutch lever ...3-8 Shift pedal ...3-8 Brake lever ...3-8...
  • Page 8 Matte color caution ...7-1 Care ...7-1 Storage ...7-3 SPECIFICATIONS ...8-1 CONSUMER INFORMATION...9-1 Identification numbers ...9-1 Reporting safety defects ...9-3 Motorcycle noise regulation ...9-4 Maintenance record ...9-5 YAMAHA MOTOR CORPORATION, U.S.A. STREET AND ENDURO MOTORCYCLE LIMITED WARRANTY ...9-7 YAMAHA EXTENDED SERVICE (Y.E.S.) ...9-9...
  • Page 9: Safety Information

    EAU10281 MOTORCYCLES SINGLE TRACK VEHICLES. THEIR SAFE USE AND OPERATION ARE DEPENDENT UPON THE USE OF PROPER RIDING TECHNIQUES AS WELL AS THE EX- PERTISE OF THE OPERATOR. EV- ERY OPERATOR SHOULD KNOW THE FOLLOWING REQUIREMENTS BEFORE RIDING THIS MOTOR- CYCLE.
  • Page 10 A passenger should also observe the above precautions. Modifications Modifications made to this motorcycle not approved by Yamaha, or the re- moval of original equipment, may ren- der the motorcycle unsafe for use and may cause severe personal injury. Modifications may also make your motorcycle illegal to use.
  • Page 11 Accessories Genuine Yamaha accessories have been specifically designed for use on this motorcycle. Since Yamaha cannot test all other accessories that may be available, you must personally be re- sponsible for the proper selection, in- stallation and use of non-Yamaha accessories.
  • Page 12 SAFETY INFORMATION tor and may limit control ability, therefore, such accessories are not recommended. Use caution when adding electri- cal accessories. If electrical acces- sories exceed the capacity of the motorcycle’s electrical system, an electric failure could result, which could cause a dangerous loss of lights or engine power.
  • Page 13: Location Of Important Labels

    SAFETY INFORMATION EAU10381 Location of important labels Please read the following important labels carefully before operating this vehicle.
  • Page 14 SAFETY INFORMATION Cold tire normal pressure should be set as follows. 2.80 2.80 California only 1D7-21668-00...
  • Page 15: Description

    Left view 1. Front turn signal/position lights (page 6-34) 2. Headlight (page 6-32) 3. Seat lock (page 3-11) 4. Fuel injection system fuse (page 6-30) 5. Fuse box (page 6-30) 6. Main fuse (page 6-30) 7. Helmet holder (page 3-12) 8.
  • Page 16: Right View

    DESCRIPTION Right view 1. Tail/brake light (page 6-33) 2. Rear brake fluid reservoir (page 6-22) 3. Owner’s tool kit (page 6-1) 4. Battery (page 6-29) 5. Air filter element (page 6-15) 6. Fuel tank cap (page 3-9) 7. Front brake fluid reservoir (page 6-22) 8.
  • Page 17: Controls And Instruments

    DESCRIPTION EAU10430 Controls and instruments 1. Clutch lever (page 3-8) 2. Left handlebar switches (page 3-6) 3. Multi-function meter unit (page 3-3) 4. Main switch/steering lock (page 3-1) 5. Right handlebar switches (page 3-6) 6. Throttle grip (page 6-16) 7. Brake lever (page 3-8)
  • Page 18: Instrument And Control Functions

    INSTRUMENT AND CONTROL FUNCTIONS Main switch/steering lock The main switch/steering lock controls the ignition and lighting systems, and is used to lock the steering. The various positions are described below. All electrical circuits are supplied with power, and the meter lighting, taillight, license plate light and position lights come on, and the engine can be start- ed.
  • Page 19: Indicator And Warning Lights

    “ON”. If the warning light does not come on for a few seconds, and then go off, have a Yamaha dealer check the elec- trical circuit. NOTE: The vehicle must be on a level sur-...
  • Page 20: Multi-Function Meter Unit

    The fuel level warning light will flash eight times, and then go off for 3.0 seconds. If this occurs, have a Yamaha dealer check the vehicle. Coolant temperature warning light “ ”...
  • Page 21 a fuel reserve tripmeter (which shows the distance traveled on the fuel reserve) a clock a self-diagnosis device a brightness control mode NOTE: Be sure to turn the key to “ON” before using the “SELECT” switch “ and “RESET” switch, except for setting the brightness control mode.
  • Page 22 (e.g., 12, 13, 14). If the odometer/tripmeter/clock display indicates any error codes, note the code number, and then have a Yamaha dealer check the vehicle. ECA11590 CAUTION: If the display indicates an error...
  • Page 23: Handlebar Switches

    Brightness control mode 1. Speedometer panel 2. Brightness level This function allows you to adjust the brightness of the speedometer panel to suit the outside lighting conditions. To set the brightness 1. Turn the key to “OFF”. 2. Push and hold the “ ”...
  • Page 24 INSTRUMENT AND CONTROL FUNCTIONS Right 1. Engine stop switch “ ” 2. “SELECT” switch “ ” 3. “RESET” switch 4. Start switch “ ” Dimmer switch “ ” Set this switch to “ ” for the high beam and to “ ”...
  • Page 25: Clutch Lever

    EAU12820 Clutch lever 1. Clutch lever The clutch lever is located at the left handlebar grip. To disengage the clutch, pull the lever toward the handle- bar grip. To engage the clutch, release the lever. The lever should be pulled rapidly and released slowly for smooth clutch operation.
  • Page 26: Brake Pedal

    INSTRUMENT AND CONTROL FUNCTIONS Brake pedal 1. Brake pedal The brake pedal is on the right side of the motorcycle. To apply the rear brake, press down on the brake pedal. EAU12941 Fuel tank cap 1. Fuel tank cap lock cover 2.
  • Page 27: Fuel

    Your Yamaha engine has been de- signed to use regular unleaded gaso- line with a pump octane number [(R+M)/2] of 86 or higher, or a research octane number of 91 or higher.
  • Page 28: Catalytic Converter

    INSTRUMENT AND CONTROL FUNCTIONS Catalytic converter This model is equipped with a catalytic converter in the exhaust system. WARNING The exhaust system is hot after op- eration. Make sure that the exhaust system has cooled down before do- ing any maintenance work. CAUTION: The following precautions must be observed to prevent a fire hazard or...
  • Page 29: Helmet Holder

    It is recommended to have a Yamaha dealer adjust the spring preload. ECA10100 CAUTION: Never attempt to turn an adjusting mechanism beyond the maximum or minimum settings.
  • Page 30: Sidestand

    Do not deform or damage the gas cylinder in any way, as this will result in poor damping per- formance. Always have a Yamaha dealer service the shock absorber. EWA10220 3-13 EAU15301 Sidestand The sidestand is located on the left side of the frame.
  • Page 31: Ignition Circuit Cut-Off System

    Yamaha dealer re- pair it if it does not function proper- INSTRUMENT AND CONTROL FUNCTIONS EAU15311 Ignition circuit cut-off system The ignition circuit cut-off system (com- prising the sidestand switch, clutch switch and neutral switch) has the fol- lowing functions.
  • Page 32 This check is most reliable if performed with a warmed-up engine. The neutral switch may be defective. The motorcycle should not be ridden until checked by a Yamaha dealer. The sidestand switch may be defective. The motorcycle should not be ridden until checked by a Yamaha dealer.
  • Page 33: Pre-Operation Checks

    PRE-OPERATION CHECKS EAU15591 The condition of a vehicle is the owner’s responsibility. Vital components can start to deteriorate quickly and unexpectedly, even if the vehicle remains unused (for example, as a result of exposure to the elements). Any damage, fluid leakage or loss of tire air pressure could have serious consequences.
  • Page 34: Pre-Operation Check List

    • If necessary, add recommended coolant to specified level. • Check cooling system for leakage. • Check operation. • If soft or spongy, have Yamaha dealer bleed hydraulic system. • Check lever free play. • Adjust if necessary. Front brake •...
  • Page 35 ITEM • Make sure that operation is smooth. • Check cable free play. Throttle grip • If necessary, have Yamaha dealer adjust cable free play and lubricate cable and grip housing. • Make sure that operation is smooth. Control cables •...
  • Page 36: Operation And Important Riding Points

    NOTE: EWA10290 When the transmission is in the neutral position, the neutral indicator light engine, should be on, otherwise have a Yamaha dealer check the electrical cir- cuit. procedure 3. Start the engine by pushing the start switch. NOTE: If the engine fails to start, release the start switch, wait a few seconds, and then try again.
  • Page 37: Shifting

    ECA11130 CAUTION: For maximum engine life, always warm the engine up before starting off. Never accelerate hard when the engine is cold! NOTE: The engine is warm when it quickly re- sponds to the throttle. OPERATION AND IMPORTANT RIDING POINTS EAU16671 Shifting 1.
  • Page 38: Engine Break-In

    OPERATION AND IMPORTANT RIDING POINTS 4. At the recommended shift points shown in the following table, close the throttle, and at the same time, quickly pull the clutch lever in. 5. Shift the transmission into second gear. (Make sure not to shift the transmission into the neutral posi- tion.) 6.
  • Page 39: Parking

    The vehicle can now be operated nor- mally. ECA10270 CAUTION: If any engine trouble should occur during the engine break-in period, immediately have a Yamaha dealer check the vehicle. OPERATION AND IMPORTANT RIDING POINTS EAU17212 Parking When parking, stop the engine, and then remove the key from the main switch.
  • Page 40: Periodic Maintenance And Minor Repair

    NOTE: If you do not have the tools or experi- ence required for a particular job, have a Yamaha dealer perform it for you. EAU17350...
  • Page 41 PERIODIC MAINTENANCE AND MINOR REPAIR EWA10340 WARNING Modifications approved Yamaha may cause loss of perfor- mance, excessive emissions, and render the vehicle unsafe for use. Consult a Yamaha dealer before at- tempting any changes.
  • Page 42: Periodic Maintenance Chart For The Emission Control System

    • Check control system for dam- sion control system age. (For California only) • Replace if necessary. * Since these items require special tools, data and technical skills, have a Yamaha dealer perform the service. INITIAL 600 mi 4000 mi ROUTINE...
  • Page 43: General Maintenance And Lubrication Chart

    General maintenance and lubrication chart ITEM • Check condition and damage. 1 * Air filter element • Replace if necessary. • Check operation. 2 * Clutch • Adjust or replace cable. • Check operation, fluid level, and 3 * Front brake for fluid leakage.
  • Page 44 PERIODIC MAINTENANCE AND MINOR REPAIR ITEM • Check bearing assemblies for Swingarm pivot looseness. bearings • Moderately repack with lithium- soap-based grease. • Check belt tension. 10 * Drive belt • Adjust if necessary. • Check bearing assemblies for looseness. 11 * Steering bearings •...
  • Page 45 24 months. Front and rear brake 23 * • Check operation. switches • Apply Yamaha chain and cable 24 * Control cables lube or engine oil SAE 10W-30 thoroughly. • Check operation and free play. • Adjust the throttle cable free play...
  • Page 46 • Adjust headlight beam. * Since these items require special tools, data and technical skills, have a Yamaha dealer perform the service. NOTE: From 24000 mi (37000 km) or 36 months, repeat the maintenance intervals starting from 8000 mi (13000 km) or 12 months.
  • Page 47: Removing And Installing Panels

    EAU18771 Removing and installing pan- The panels shown need to be removed to perform some of the maintenance jobs described in this chapter. Refer to this section each time a panel needs to be removed and installed. 1. Panel A 2.
  • Page 48: Checking The Spark Plugs

    PERIODIC MAINTENANCE AND MINOR REPAIR 1. Panel C 2. Bolt 3. Quick fastener screw 4. Panel B To install the panels Fit the tabs on panel B into the corre- sponding slots in panel C, place the panels in their original positions, and then install the bolts and the quick fas- tener screws.
  • Page 49: To Check/Install Spark Plug

    Do not attempt to PERIODIC MAINTENANCE AND MINOR REPAIR diagnose such problems yourself. In- stead, have a Yamaha dealer check the vehicle. 3. Check each spark plug for elec- trode erosion and excessive car- bon or other deposits, and replace it if necessary.
  • Page 50: Canister (For California Only)

    PERIODIC MAINTENANCE AND MINOR REPAIR Canister (for California only) This model is equipped with a canister to prevent the discharging of fuel vapor into the atmosphere. Before operating this vehicle, make sure to check the fol- lowing: Check each hose connection. Check each hose and canister for cracks or damage.
  • Page 51 PERIODIC MAINTENANCE AND MINOR REPAIR 1. Oil filter cartridge 2. Oil filter wrench NOTE: An oil filter wrench is available at a Yamaha dealer. 5. Apply a thin coat of engine oil to the O-ring of the new oil filter car- tridge. 6-12 1.
  • Page 52 ECA10400 CAUTION: If the oil level warning light flickers or remains on, immediately turn the engine off and have a Yamaha dealer check the vehicle. 10. Turn the engine off, and then check the oil level and correct it if...
  • Page 53: Coolant

    EAU20070 Coolant The coolant level should be checked before each ride. In addition, the cool- ant must be changed at the intervals specified in the periodic maintenance and lubrication chart. EAU42630 To check the coolant level 1. Place the vehicle on a level sur- face and hold it in an upright posi- tion.
  • Page 54: Replacing The Air Filter Element

    PERIODIC MAINTENANCE AND MINOR REPAIR If water has been added to the coolant, have a Yamaha dealer check the antifreeze content of the coolant as soon as possible, otherwise the effectiveness of the coolant will be reduced. WARNING Never attempt to remove the radiator cap when the engine is hot.
  • Page 55: Checking The Throttle Cable Free Play

    The throttle cable free play should mea- sure 4.0–6.0 mm (0.16–0.24 in) at the throttle grip. Periodically check the throttle cable free play and, if neces- sary, have a Yamaha dealer adjust it. 6-16 EAU21401 Valve clearance The valve clearance changes with use, resulting in improper air-fuel mixture and/or engine noise.
  • Page 56: Tires

    PERIODIC MAINTENANCE AND MINOR REPAIR Tires To maximize the performance, durabil- ity, and safe operation of your motor- cycle, note following regarding the specified tires. Tire air pressure The tire air pressure should be checked and, if necessary, adjusted before each ride.
  • Page 57: Cast Wheels

    Yamaha dealer immediately and have the tire replaced. Minimum tire tread depth (front and rear): 1.0 mm (0.04 in) EWA10520 WARNING It is dangerous to ride with a worn- out tire.
  • Page 58: Accessories And Replacement Parts

    Since Yamaha cannot control the quality of accessories or parts man- ufactured other companies, Yamaha cannot be held liable for EAU22011 any consequences caused by the use of items which have not been approved by Yamaha. EWA10621...
  • Page 59: Adjusting The Brake Lever Free Play

    3. If the specified clutch lever free play could be obtained as de- scribed above, tighten the locknut and skip the rest of the procedure, otherwise, proceed as follows. 4. Fully turn the adjusting bolt in di- rection (a) to loosen the clutch ca- ble.
  • Page 60: Adjusting The Rear Brake Light Switch

    A soft or spongy feeling in the brake lever can indicate the presence of air in the hydraulic system. If there is air in the hy- draulic system, have a Yamaha dealer bleed the system before operating the motorcycle. Air in the hydraulic system will dimin-...
  • Page 61: Checking The Brake Fluid Level

    Yamaha dealer replace the brake pads as a set. EAU22500 Rear brake pads 1. Lining thickness Check each rear brake pad for damage and measure the lining thickness. If a brake pad is damaged or if the lining thickness is less than 0.8 mm (0.03 in),...
  • Page 62: Changing The Brake Fluid

    Yamaha dealer check the cause. Changing the brake fluid Have a Yamaha dealer change the brake fluid at the intervals specified in the NOTE after the periodic mainte- nance and lubrication chart. In addition,...
  • Page 63: Checking And Lubricating The Cables

    2 from the measurement noted in step 3. Drive belt slack: 5.0–7.0 mm (0.20–0.28 in) 5. If the drive belt slack is incorrect, have a Yamaha dealer adjust it. PERIODIC MAINTENANCE AND MINOR REPAIR EAU23091 Checking and lubricating the cables...
  • Page 64: Checking And Lubricating The Brake And Shift Pedals

    PERIODIC MAINTENANCE AND MINOR REPAIR Checking and lubricating the brake and shift pedals The operation of the brake and shift pedals should be checked before each ride, and the pedal pivots should be lu- bricated if necessary. EAU23131 Recommended lubricant: Lithium-soap-based grease (all-pur- pose grease) 6-25...
  • Page 65: Checking And Lubricating The Sidestand

    EWA10730 WARNING If the sidestand does not move up and down smoothly, have a Yamaha dealer check or repair it. Recommended lubricant: Lithium-soap-based grease (all-pur- pose grease) 6-26 EAUM1650...
  • Page 66: Lubricating The Rear Suspension

    6-27 EAU23271 EWA10750 CAUTION: If any damage is found or the front fork does not operate smoothly, have a Yamaha dealer check or re- pair it. ECA10590...
  • Page 67: Checking The Steering

    2. Hold the lower ends of the front fork legs and try to move them for- ward and backward. If any free play can be felt, have a Yamaha dealer check or repair the steering. PERIODIC MAINTENANCE AND MINOR REPAIR...
  • Page 68: Battery

    IES OUT OF THE REACH OF CHILDREN. To charge the battery Have a Yamaha dealer charge the bat- tery as soon as possible if it seems to have discharged. Keep in mind that the battery tends to discharge more quickly if the vehicle is equipped with optional electrical accessories.
  • Page 69: Replacing The Fuses

    Using a conventional battery charger will damage the battery. If you do not have access to a sealed-type (MF) battery charg- er, have a Yamaha dealer charge your battery. PERIODIC MAINTENANCE AND MINOR REPAIR EAU42580 Replacing the fuses...
  • Page 70 4. Turn the key to “ON” and turn on the electrical circuit in question to check if the device operates. 5. If the fuse immediately blows again, have a Yamaha dealer check the electrical system. 6-31 6. Install the battery cover, and then hook the battery band onto the holder.
  • Page 71: Replacing The Headlight Bulb

    EAU42470 Replacing the headlight bulb This model is equipped with a quartz bulb headlight. If the headlight bulb burns out, replace it as follows. 1. Remove the turn signal/position light bracket cover by removing the bolts. 1. Turn signal/position light bracket cover 2.
  • Page 72: Replacing The Tail/Brake Light Bulb

    7. Install the headlight unit by install- ing the bolts. 8. Place the turn signal/position light bracket cover in the original posi- tion, and then install the bolts. 9. Have a Yamaha dealer adjust the headlight beam if necessary. 6-33 EAU24131 Replacing the tail/brake light bulb 1.
  • Page 73: Replacing A Front Turn Signal Light Bulb

    EAU42460 Replacing a front turn signal light bulb 1. Remove the front turn signal light outer lens by removing the screws. 1. Screw 2. Remove the inner lens by pulling it out. 1. Inner lens PERIODIC MAINTENANCE AND MINOR REPAIR 3.
  • Page 74: Replacing The License Plate Light Bulb

    PERIODIC MAINTENANCE AND MINOR REPAIR Replacing the license plate light bulb 1. Remove the license plate light cov- er by removing the bolts. 1. License plate light cover 2. Bolt 2. Pull the license plate light unit up as shown. 1.
  • Page 75: Supporting The Motorcycle

    The following troubleshooting charts represent quick and easy procedures for checking these vital systems your- self. However, should your motorcycle require any repair, take it to a Yamaha dealer, whose skilled technicians have the necessary tools, experience, and know-how to service the motorcycle properly.
  • Page 76: Troubleshooting Charts

    There is no compression. check the vehicle. Wipe off with a dry cloth and correct the spark plug gaps, or replace the spark plugs. Have a Yamaha dealer check the vehicle. The engine turns over The battery is good. quickly.
  • Page 77 The coolant level is low. Check the cooling system for leakage. Start the engine. If the engine overheats again, have a The coolant level Yamaha dealer check and repair the cooling system. is OK. 6-38 EWAT1040 There is Have a Yamaha dealer check leakage.
  • Page 78: Motorcycle Care And Storage

    Matte color caution CAUTION: Some models are equipped with matte colored finished parts. Be sure to consult a Yamaha dealer for advice on what products to use be- fore cleaning the vehicle. Using a brush, harsh chemical products or cleaning compounds when cleaning these parts will scratch or damage their surface.
  • Page 79 cleaning products, solvent or thinner, fuel (gasoline), rust re- movers or inhibitors, brake flu- id, antifreeze or electrolyte. Do not use high-pressure wash- ers or steam-jet cleaners since they cause water seepage and deterioration in the following ar- eas: seals (of wheel and swing- arm bearings, fork and brakes), electric components (couplers, connectors,...
  • Page 80: Storage

    Avoid using abrasive polishing compounds as they will wear away the paint. EWA11130 NOTE: Consult a Yamaha dealer for advice on what products to use. ECA10950 EAU26280 Storage Short-term Always store your motorcycle in a cool, dry place and, if necessary, protect it against dust with a porous cover.
  • Page 81 3. Perform the following steps to pro- tect the cylinders, piston rings, etc. from corrosion. a. Remove the spark plug caps and spark plugs. b. Pour a teaspoonful of engine oil into each spark plug bore. c. Install the spark plug caps onto the spark plugs, and then place the spark plugs on the cylinder head so that the electrodes are...
  • Page 82: Specifications

    SPECIFICATIONS Dimensions: Overall length: 2490 mm (98.0 in) Overall width: 980 mm (38.6 in) Overall height: 1115 mm (43.9 in) Seat height: 715 mm (28.1 in) Wheelbase: 1690 mm (66.5 in) Ground clearance: 145 mm (5.71 in) Minimum turning radius: 3500 mm (137.8 in) Weight: With oil and fuel:...
  • Page 83 Chassis: Frame type: Double cradle Caster angle: 32.70 ° Trail: 145.0 mm (5.71 in) Front tire: Type: Tubeless Size: 130/90 16M/C 67H Manufacturer/model: DUNLOP/D404F X Manufacturer/model: BRIDGESTONE/EXEDRA G721 Rear tire: Type: Tubeless Size: 170/70B 16M/C 75H Manufacturer/model: DUNLOP/K555 Manufacturer/model: BRIDGESTONE/EXEDRA G722 G Loading: Maximum load: 210 kg (463 lb)
  • Page 84 SPECIFICATIONS Rear turn signal light: 12 V, 21.0 W × 2 License plate light: 12 V, 5.0 W × 1 Meter lighting: Neutral indicator light: High beam indicator light: Oil level warning light: Turn signal indicator light: Fuel level warning light: Coolant temperature warning light: Engine trouble warning light: Fuses:...
  • Page 85: Consumer Information

    Record the key identification number, vehicle identification number and mod- el label information in the spaces pro- vided below for assistance when ordering spare parts from a Yamaha dealer or for reference in case the vehi- cle is stolen. KEY IDENTIFICATION NUMBER:...
  • Page 86 1. Model label The model label is affixed to the frame under the rider seat. (See page 3-11.) Record the information on this label in the space provided. This information will be needed when ordering spare parts from a Yamaha dealer.
  • Page 87: Reporting Safety Defects

    If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Yamaha Motor Corporation, U.S.A. If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.
  • Page 88: Motorcycle Noise Regulation

    CONSUMER INFORMATION Motorcycle noise regulation TAMPERING WITH NOISE CONTROL SYSTEM PROHIBITED: Federal law prohibits the following acts or the causing thereof: (1) The removal or rendering inoperative by any person other than for purposes of maintenance, repair, or replacement of any device or element of design incorporated into any new ve- hicle for the purpose of noise control prior to its sale or delivery to the ultimate purchaser or while it is in use or (2) the use of the vehicle after such device or element of design has been removed or rendered inoperative by any person.
  • Page 89: Maintenance Record

    Maintenance record Copies of work orders and/or receipts for parts purchased and installed on your vehicle will be required to document that maintenance has been completed in accordance with the emissions warranty. The chart below is printed only as a reminder that maintenance work is required.
  • Page 90 CONSUMER INFORMATION Maintenance interval 36000 mi (55000 km) or 54 months 40000 mi (61000 km) or 60 months Date of Mileage service Servicing dealer Remarks name and address...
  • Page 91: Yamaha Motor Corporation, U.s.a. Street And Enduro Motorcycle Limited Warranty

    YAMAHA MOTOR CORPORATION, U.S.A. STREET AND ENDURO MOTORCYCLE LIMITED WARRANTY Yamaha Motor Corporation, U.S.A. hereby warrants that new Yamaha motorcycles will be free from defects in material and workmanship for the period of time stated herein, subject to certain stated limitations.
  • Page 92 CUSTOMER SERVICE If your machine requires warranty service, you must take it to any authorized Yamaha motorcycle dealer within the continental United States. Be sure to bring your warranty registration card or other valid proof of the original date of purchase. If a question or problem arises regarding the warranty, first contact the owner of the dealership.
  • Page 93: Yamaha Extended Service (Y.e.s.)

    This excellent Y.E.S. plan coverage is only available to Yamaha owners like you, and only while your Yamaha is still within the Yamaha Limited Warranty period. So visit your authorized Yamaha dealer to get all the facts. He can show you how easy it is to protect your investment with Yamaha Extended Service.
  • Page 94 Yamaha Limited Warranty expires. A special note: If visiting your dealer isn’t convenient, contact Yamaha with your Primary ID number (your frame number). We’ll be happy to help you get the Y.E.S. coverage you need.
  • Page 95 Accessories and replacement parts ... 6-19 Air filter element, replacing ... 6-15 Battery ... 6-29 Brake and clutch levers, checking and lubricating... 6-25 Brake and shift pedals, checking and lubricating... 6-25 Brake fluid, changing ... 6-23 Brake fluid level, checking ... 6-22 Brake lever ...
  • Page 96 INDEX Troubleshooting ... 6-36 Troubleshooting charts ... 6-37 Turn signal indicator light ... 3-2 Turn signal light bulb (front), replacing ... 6-34 Turn signal light bulb (rear), replacing ... 6-34 Turn signal switch ... 3-7 Valve clearance ... 6-16 Vehicle identification number ... 9-1 Warranty, extended...
  • Page 97 YAMAHA MOTOR CO., LTD. PRINTED ON RECYCLED PAPER PRINTED IN JAPAN 2006.08-3.8×1 CR...
