This work is to be carried out by a skilled plumber.
There are different type-approved taps and tap assemblies on the market.
The water hose must not be cracked, squeezed or put in tight bends.
Before the appliance is placed its final location, ensure that the water connection has been
correctly carried out, that there is no leakage at the connection to the water tap.
Tighten the screw enough by hand.
Make sure that the gasket is properly positioned in the connector.
We recommend that the appliance is placed on a "run-off" mat intended for refrigerators
and freezers, which makes it easier to detect possible leakage

Fitting the door handles

(Example for right hinge performance)
The handles are supplied as a kit at delivery.
1. Screw the top handle bracket to the
handle rod.
2. Fit the bottom handle bracket on the
lower left-hand side of the door.
3. Fit the top handle bracket on the top
left-hand side of the door.
4. Screw the handle rod to the bottom
handle bracket.
Do not use excessive force and overtighten
the screws (max. 2 Nm) as you may damage
the door handles.
Levelling
When placing the appliance ensure that it stands
level. If necessary adjust the feet using the adjust-
ment spanner supplied.
Door alignment is dependent on proper levelling.

Installation of the Clean Air Control filter

The Clean Air Control filter is an active carbon filter which absorbs bad odours maintain the
best flavour and aroma for all foodstuffs without risk of odour cross contamination.
On delivery the carbon filter is in a plastic bag to preserve performance.
Installation
1
3
23
2
4
