Related Manuals for Electrolux EWT121
Summary of Contents for Electrolux EWT121
- Page 1 User Manual Manual Pengguna Washing Machine ... 3 Mesin Basuh ... 31 ..... 59 119730620 EWT121...
- Page 2 We were thinking of you when we made this product...
- Page 3 Thank you for choosing a first class product from Electrolux, which hopefully will provide you with lots of pleasure in the future. The Electrolux ambition is to offer a wide variety of quality products that make your life more comfortable. You find some examples on the cover in this manual.
-
Page 4: Table Of Contents
The symbols you will see on some paragraphs of this booklet have the following meaning: The warning triangle and/or the key words (Warning!, Caution!) emphasize information that is particularly important for your safety or correct functioning of the appliance. The information marked with this symbol provides additional instructions and practical tips on the use of the appliance. -
Page 5: Safety Information
SAFETY INFORMATION This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental In the interest of your safety and to capabilities, or lack of experience and ensure the correct use, before knowledge, unless they have been installing and first using the given supervision or instruction appliance, read this user manual... -
Page 6: Child Safety
If the machine is situated on a Never use the washing machine if the carpeted floor, please adjust the feet power supply cable, the control in order to allow air to circulate freely. panel, the working surface or the base are damaged so that the inside Always be sure, that there is no water of the washing machine is accessible. -
Page 7: Product Description
PRODUCT DESCRIPTION Control Panel ON - OFF Safety Glass Switch Mains Cable Water Inlet Hose Drain Hose Front Feet Back Feet Front Side View Back Side View Dispenser Drawer Fabric Softener Dispenser Wash bowl Agitator Lint filter Bleach Dispenser In Side View... -
Page 8: Out Of Balance Interruption
When you press a button you will get a Out of Balance Interruption short ‘BEEP’ to acknowledge the entry. The washing machine can stop during If the option is not available at the time, the spin stage of a wash because of an the machine will not allow you to select out of balance condition. -
Page 9: Control Panel
When the washing machine in The digital display will be “ ” STAND-BY-MODE or PAUSE MODE, when the end of wash beeping is press and hold “Start/Hold To Pause” disabled. buttons simultaneously for about 3 Press the “Modify Option ( )”... -
Page 10: Use
Follow the instructions in this section for Check your clothes to avoid best washing results. damage Empty all pockets. Close all hooks and Sort Your Washing Into zippers to avoid snagging clothes. Separate Wash Loads Wash bras, pantyhose and other delicates in a mesh laundry bag, which you can purchase from your supermarket. -
Page 11: Add The Detergent
Clothes must be loaded evenly Add the detergent around the agitator. For best results load small items first, followed by When using the washing machine for large items. the first time, check that the dispenser is set for the type of detergent you will Clothes must not be wrapped a use. -
Page 12: Add Fabric Softener
Add Fabric Softener Measure the correct amount of fabric softener by following the recommendations on the package. If you are going to use intensive fabric softener, mix softener with an equal amount of warm water but only mix enough to fill to the line marked inside the cup. -
Page 13: Adding Bleach
Adding Bleach You can now wash the clothes load using detergent and your selected wash program. NOTE: Bleach should not be used on silk, wool, rayon or drip dry clothes. Operating Your Washing Machine Starting your washing machine Bleaching of clothes can help to remove Turn on the taps and turn power on stains, heavy soiling and to kill bacteria. -
Page 14: Program Option Buttons
Select The Required Program NOTE: When you choose the WOOLLENS and BEDDING program, the DEEP RINSE option is automatically selected for you. You will not be able to select and use Eco Rinse and Fast Rinse with these two programs. When you select the DRAIN+SPIN program, there will be a delay of at least 2 minute before the washing machine... - Page 15 Wash Load Option We advise you to use AUTO load level whenever you can. The AUTO load level ensures just the right amount of water is used for the wash load. Use only the amount of water you need for the wash load. If you want to add more water after wash cycle has started, press and hold the “Start/Hold To Pause”...
-
Page 16: Rinse Option
Rinse Option The Dirt Level option chosen will have an influence on the wash time of the selected wash program. For the same wash program, High Dirty Level will have a longer wash time than Regular Dirty Level, and Regular Dirty Level a longer wash time than Light &... - Page 17 Reduce Time Option This option allows you to reduce washing time at the washing process. By pressing ‘Reduce Time’ button, then press the modify option buttons The machine will go through a series of decrease or to back to default maximum six pulse spray and short agitation time.
-
Page 18: Lid Locked
Delay End Option Lid Locked ( Before you start the program, this The padlock symbol is displayed on option makes it possible to define the the screen to advise you when the lid of the washing machine is locked in the end of the washing program by 2, 4, 6 closed position. -
Page 19: Incorrect Option Selection
Display End Of Program The display showns the following information: Machine In Pause Mode When the program is completed the 4 zeros will flash. Alarm Codes You can tell when your washing machine is in PAUSE mode. The message “ ”... -
Page 20: Washing Hints
WASHING HINTS Sorting The Laundry Removing Stains Stubborn stains may not be removed by Follow the wash code symbols on just water and detergent. It is therefore each garment label and the advisable to treat them prior to washing. manufacturer’s washing instructions. Blood: treat fresh stains with cold water. -
Page 21: Detergents And Additives
Quantity Of Detergent To Be Ink: depending on the type of ink, moisten the fabric first with acetone (*), Used then with acetic acid; treat any residual The type and quantity of detergent will marks on white fabrics with bleach and depend on the type of fabric, load size, then rinse thoroughly. -
Page 22: Washing Program
WASHING PROGRAMS Icon Program Description Options Wash Load / Dirt Level / Soak Time / Regular For an average domestic load Rinse Option / Delay End of mixed fabrics. Wash Wash Load / Dirt Level / Fast Soak Time (only ‘No Soak’) / For a very small load of Rinse Option (can not select ‘Extra’) / Wash... -
Page 23: Care And Cleaning
CARE AND CLEANING What To Do After You Have Before replacing the dispenser back in its recess, clean the inside of the Finished Your Washing. drawer with an old toothbrush. Press ‘OFF’ at the ON - OFF Switch. Switch off the electricity at the power point. - Page 24 Cleaning Stains In The Unclip the filter bag from the column. Washbowl Stains and residue in the washbowl can be caused by: Metal objects such as bobby pins, dress making pins and nails. Salt. Body oils and grease from very dirty Turn the bag inside out and remove or sweaty clothes being deposited the lint.
-
Page 25: Helpful Hints In Dealing With Washing Problems
HELPFUL HINTS IN DEALING WITH WASHING PROBLEMS Residues On Washed Items If you use pre-treatment sprays or stain removers, apply them to the clothes If you are experiencing residue on some items in a well ventilated area away clothes, the following tips will help: from your washing machine. -
Page 26: Yellowing Or Greying Clothes
Yellowing Or Greying Clothes Problem Possible causes What to do 1. ONLY use low sudsing detergent Incorrect wash times and for washing machine. using insufficient detergent which can cause redepositing 2. Re-sort load, then re-wash using of detergent on clothes. program selections suitable for the fabric. -
Page 27: Troubleshooting
TROUBLESHOOTING Before call for servicing if you notice the problem as guidance on the table below. It will be helpful your solution with some temporary symptom. You washing machine will comeback to work as normal before service people coming or waiting any queueing from service provider. For some problems you will get a message in the display screen accompanied by ‘Beeps’. -
Page 28: Troubleshooting Fault Displays
Problem Display Code Possible Causes What to do Check detergent use and Not enough or no detergent rewash clothes Too many clothes in load Remove some clothes and Clothes still dirty after rewash wash program Incorrect wash program or Reselect program or temperature and rewash temperature selected Use a higher water level... - Page 29 Display Code Description Customer action (Summary) Wait a few minutes to see if the fault is corrected. If not, press ‘Start/Hold To Pause’ then check the drain hose for blockage. Press ‘Start/Hold To Pause’ Draining problem to continue the wash. If problem remains, call Service.
-
Page 30: Environment Concerns
ENVIRONMENT CONCERNS Packaging materials Ecological hints To save water, energy and to help protect the environment, we recommend that you follow these tips: The materials marked with the symbol are recyclable. Normally soiled laundry may be washed without prewashing in order >PE<=polyethylene to save detergent, water and time >PS<=polystyrene... - Page 32 www.electrolux.com...
