TRENDnet User's Guide
Router Maintenance & Monitoring

Reset your router to factory defaults

Tools > Settings
You may want to reset your router to factory defaults if you are encountering difficulties
with your router and have attempted all other troubleshooting. Before you reset your
router to defaults, if possible, you should backup your router configuration first, see
"Backup and restore your router configuration settings" on
There are two methods that can be used to reset your router to factory defaults.
• Reset Button – Located on the rear panel of your router, see "Product
Hardware Features" on page 2
difficulties with accessing your router management page.
OR
• Router Management Page
1. Log into your router management page (see "Access your router management page"
on page 27).
2. Click on Tools and click on Settings.
3. Under Restore factory default settings, click Restore. When prompted to confirm this
action, click OK.
© Copyright 2012 TRENDnet. All Rights Reserved.
page 42.
. Use this method if you are encountering

Router Default Settings

Administrator User Name
Administrator Password
Router IP Address
Router Subnet Mask
DHCP Server IP Range
Wireless
SSID (wireless network name)
Wireless Security
802.11 Mode
Channel
TEW-731BR
admin
admin
192.168.10.1
255.255.255.0
192.168.10.101-192.168.199
Enabled
TRENDnet731
Disabled
2.4GHz 802.11b/g/n mixed mode
Auto Channel
41
