User Manual for your
BTW600ME
60 cm Integrated
hood
NOTE
: This User Instruction Manual contains important
information, including safety & installation points, which will
enable you to get the most out of your appliance. Please keep it
in a safe place so that it is easily available for future reference; for
you or any person not familiar with the operation of the appliance.
GS 27/02/12

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BTW600ME and is the answer not in the manual?

Questions and answers

Related Manuals for Baumatic BTW600ME

Summary of Contents for Baumatic BTW600ME

  • Page 1 User Manual for your BTW600ME 60 cm Integrated hood NOTE : This User Instruction Manual contains important information, including safety & installation points, which will enable you to get the most out of your appliance. Please keep it in a safe place so that it is easily available for future reference; for you or any person not familiar with the operation of the appliance.

  • Page 2: Table Of Contents

    Contents Page Environmental note IMPORTANT SAFETY INFORMATION 4 – 6 Specifications of your cooker hood Using your cooker hood 8 – 9 Before first use To use your cooker hood 8 – 9 Turning the cooker hood off Cleaning your cooker hood Cleaning The grease filter Maintenance...

  • Page 3: Environmental Note

    ENVIRONMENTAL NOTE Note: Before discarding an old appliance, switch off and disconnect it from the power supply. Cut off and render any plug useless. Cut the cable off directly behind the appliance to prevent misuse. This should be undertaken by a competent person.

  • Page 4: Important Safety Information

    IMPORTANT SAFETY INFORMATION Your safety is of the utmost importance to us. Please make sure that you read this instruction booklet before attempting to install or use the appliance. If you are unsure of any of the information contained in this booklet, please contact the Advice L ine.
  • Page 5 o The edges of the cooker hood are sharp – be mindful of this as you handle your appliance, especially during installation and cleaning. DO NOT CLEAN IN BEHIND THE GREASE FILTER! o If the room where the cooker hood is to be used contains a fuel burning appliance such as a central heating boiler then its flue must be of the sealed or balanced flue type.
  • Page 6 o Remember that when in extraction mode, your cooker hood is removing air from your room. Ensure that proper ventilation measures are being observed. o Note that the cooker hood removes odours from your kitchen, not steam. o Warning - Always ensure that the cooker hood been disconnected...

  • Page 7: Specifications Of Your Cooker Hood

    Specifications of your cooker hood DIMENSIONS: Width: 600 mm Depth: 282 mm Height: 395 mm Your Cooker Hood is fitted with: o Integrated axial motor o Slider control operation o 3 Speeds o 1 light o 1 synthetic grease filter o Extraction capacity: 250 m³/hr o Noise level: 45 / 50 / 55 dB Optional Extra:...

  • Page 8: Using Your Cooker Hood

    Using your cooker hood Before first use IMPORTANT: THIS PROCESS MUST BE FOLLOWED BEFORE THE COOKER HOOD IS USED FOR THE FIRST TIME. o You should clean the appliance using a brand new cloth, with warm soapy water before using the appliance for the first time. You should then dry it thoroughly using a soft cloth.

  • Page 9: Turning The Cooker Hood Off

    Motor speed control switch = Off = Low speed = Medium speed = High speed o When you next turn the cooker hood on, the motor speed will remain the same as when you last used it unless you switch the motor speed to 0.

  • Page 10: Cleaning Your Cooker Hood

    Cleaning your cooker hood IMPORTANT: BEFORE CLEANING, ALWAYS ENSURE THAT YOU HAVE SWITCHED YOUR COOKER HOOD OFF AT THE OMNI-POLAR SWITCH, SET AT THE WALL FROM THE CABLE. Cleaning o Clean the external parts of your cooker hood with mild liquid detergent and a new damp cloth.

  • Page 11: Maintenance

    Maintenance Removing and cleaning the grease filter o Locate the two catches at the base of the filter as shown in the diagram above (1). o Insert a finger into each catch and gently lift and pull the filter outwards (2). o Ensure the filter unclips from the hood, as shown in the diagram above (3), before you pull it away.

  • Page 12: Changing A Light Bulb

    o Remove the metal wires which hold the synthetic filter in place. o Remove the synthetic filter and replace with a new clean one. o Reattach the metal wires in their original positions to secure the synthetic filter in place. o Refit the filter in the cooker hood.

  • Page 13: Fitting The Carbon Filters

    o You should use a suitable screwdriver to loosen the screws holding the panel into place. Once this is removed, you will have access to the bulb. o Unscrew the light bulb and insert a new olive shaped bulb with an E14 coupling 40W (max).
  • Page 14 o Insert a finger into each catch and gently lift and pull the filter outwards (2). o Ensure the filter unclips from the hood, as shown in the diagram above (3), before you pull it away. This will allow you access to the motor where the carbon filter should be fitted.

  • Page 15: Installation

    Installation IMPORTANT: Before installation and usage read all the instructions and make sure that the voltage (V) and the frequency (Hz) indicated on the rating plate are exactly the same as the voltage and frequency in your home. The rating plate can be found behind the grease filter.

  • Page 16: Before Beginning Installation

    Before beginning installation o Check that the product purchased is of a suitable size for the chosen installation area. In addition check whether there is an electrical socket available that will be accessible once the hood is mounted. If the product is going to be used in extraction mode, then there should also be space to connect a ducting hose to the outside.

  • Page 17: Installing Your Cooker Hood

    o Do not tile, grout or silicone this appliance to the wall or cabinetry. This appliance is designed to be surface mounted only. Installing your cooker hood IMPORTANT: YOU WILL HAVE TO DECIDE BEFORE INSTALLING YOUR COOKER HOOD WHETHER TO USE EXTRACTION MODE RECIRCULATION...
  • Page 18 o Insert a finger into each catch and gently lift and pull the filter outwards (2). o Ensure the filter unclips from the hood, as shown in the diagram above (3), before you pull it away. o Install the cooker hood between two cupboards. o Drill and insert the screws onto the side boards of the cupboards (the holes should be no larger than 2 mm).
  • Page 19 o Hang the cooker hood onto the screws between the two cupboards. o Push the fan-shaped door frames to the end (fully closed), in order to ensure the outer edges of the door frames parallel to the outer edge of the adjacent cupboards (not the doors).

  • Page 20: Installing The Décor Door

    Installing the décor door o The door should be no less than 16 mm thick, 385-700 mm high and weigh no more than 7 kg. o Pull out the movable fan-shaped door frames, which are located in two curved plastic slides on each side of the cooker hood.
  • Page 21 o If the upper edge of the door is not as high as the upper edge of the cupboards then you should adjust the size accordingly. o Mark the positions of the screws on the door and ensure the size is as accurate as 569+1 mm.

  • Page 22: Connecting To External Ducting

    o Install the adjusting plate, in order to cover the gap between the wall and the bottom of the cooker hood, by screwing it into place. Connecting to external ducting o To use the applian ce in extraction mode it is necessary to install external ducting.

  • Page 23: Extraction Mode Or Recirculation Mode

    Extraction mode or recirculation mode? IMPORTANT: YOU WILL HAVE TO DECIDE BEFORE INSTALLING YOUR COOKER HOOD WHETHER TO USE EXTRACTION MODE RECIRCULATION ODE. What is the difference between extraction and recirculation modes? In extraction mode, the stale air will be taken via the grease filter and out of the room via external ducting.

  • Page 24: Troubleshooting

    Troubleshooting IMPORTANT: If your cooker hood appears not to be operating properly, before contacting the Advice Line, please refer to the checklist below. My cooker hood will not start. o Check that the hood is connected to the electricity supply Check that the fan speed control is set correctly.
  • Page 25 IMPORTANT: If your appliance appear s not to be operating correctly, then you should disconn ect it from your mains supply and then contact the Advice Line on telephone number (0118) 933 6918. DO NOT ATTEMPT TO REPAIR THE APPLIANCE YOURSELF.

  • Page 28: Contact Details

    United Kingdom 6 Bennet Road, Reading, Berkshire RG2 0QX ted Kingdo Customer Care (0118) 933 6918...
