Chapter 1 Introduction

1.1. Features Summary

Form Factor
CPU
Chipset
Memory
I/O Control
Expansion Slots
On-Board SATA RAID
On-Board Peripherals
Hardware Monitor
On-Board Graphic
On-Board LAN
12" x 9.6" ATX size form factor, 4 layers PCB
Supports AMD Opteron
® TM
AMD Single/Dual Core in AM2 socket
TM
L2 cache on-die per processor from 1M
NVIDIA GeForce 6150 Chipset
®
NVIDIA nForce 430 Chipset
®
4 x DDRII-533/667 socket up to 16 GB
Supports Un-buffered DDRII 533/667
Dual Channel memory bus
Support 512MB, and 1GB memory
Single-bit Errors Correction, Multiple-bit Errors Detection
ITE IT8712F-A Super I/O
Supports 3 PCI slots 32-Bit/33MHz (5V)
Supports 1 PCI-Express x1 slot
Supports 1 PCI-Express x16 slot
Build in NVIDIA nForce 430 chipset
®
Supports SATAII RAID 0, 1, 0+1, 5
2 ATA-133 connectors
1 Floppy port supports 2 FDD with 1.2M, 1.44M and 2.88M bytes.
2 PS/2 connectors
1 Parallel port supports Normal/EPP/ECP mode
2 Serial port (COM, 1 by cable)
6 x USB 2.0 (4 by cable)
1 VGA connector
2 x LAN RJ45
4 x SATAII connectors
CPU/Power/System Fan Revolution Detect
CPU shutdown when overheat
System Voltage Detect
Integrated in NVIDIA GeForce 6150 Chipset
®
Marvell 88E8056 GbE controller/Marvell 88E1116 GbE PHY
Supports WOL, PXE
5
1000 series (Socket AM2) processor
