Gigabyte AMD Socket AM2 Motherboard GA-3PXSL-RH User Manual page 21

M ) COMB
N ) Battery
If you want to erase CMOS...
1.Turn OFF the computer and unplug the power cord.
2.Remove the battery, wait for 30 second.
3.Re-install the battery.
4.Plug the power cord and turn ON the computer.
Pin No.
9 10 1
2
3
4
5
6
7
8
1 2
9
10
CAUTION
Danger of explosion if battery is incorrectly
replaced.
Replace only with the same or equivalent
type recommended by the manufacturer.
Dispose of used batteries according to the
manufacturer's instructions.
2 1
Connector Introduction
Definition
DCD-
SIN2
SOUT2
DTR2-
GND
DSR2-
RTS2-
CTS2-
RI2-
Key Pin
