Gianni Industries CP-24G Specification

CP-24W
CP-24G
CP-24W-L
(Backlight)
CP-24G-L
Statement
The CP-24 series Break Glass call points
pole, change contacts from N/C to N/O. The main function is to
override the electrical locking/release devices in case of
emergency. A key is used to replace glass. L types have
backlight.
Specification
Dimensions: 87x87x55 mm
Contact resistance: 50mΩ
Switch rating: 1A/125VAC
Current draw (Backlight):25mA/12VDC; 45mA/24VDC
N/O
Com.
N/C
(Backlight)
12~24VDC IN
N/O
Com.
N/C
Copyright © Gianni Industries, Inc. All rights reserved.
DM-CA-CP-24 Ver. E Published on 2011.03.22
CP-24Y
CP-24R
CP-24R-L
CP-24Y-L
Patent No.:
M328067 (Taiwan)
ZL 2007 2 0175576.7 (China)
, with quadruple
N/O
Com.
N/C
(Backlight)
12~24VDC OUT
N/O
Com.
N/C
Break Glass call point
Dimensions
(European Size)
Polycarbonate
Hinged Cover
Auxiliary Key
(to change the broken glass)
Application
Electromagnetic
locks (locked)
s
l o c k
E M
Electromagnetic
locks (Unlocked)
Warranty
The product is warranted against defects in material and
workmanship while used in normal service for a period of 1
year from the date of sale to the original client. The GEM policy
is one of continual development and improvement; therefore
GEM reserves the right to change specifications without
notice.
GIANNI INDUSTRIES, INC.
No. 13, Zhongxing Rd., Tucheng Dist., New Taipei
City 236,Taiwan (R.O.C.)
Tel: 886-2 2267 7986 / Fax: 886-2 2267 9876
E-Mail: inquiry@gianni.com.tw
Website: gianni.tw
5 5
8 7
E M
D O E R
O R G E
N C
R E
Y
L E
A S
E
B R
8 7
E A
K G
L A
P R
S S
E S
S H
E R
E
Unit: mm
N/O N/O
Com. Com.
N/C N/C
N/O N/O Alarm
Com. Com.
N/C N/C
(Glass is broken)
N/O N/O
Com. Com.
N/C N/C
Alarm
N/O N/O
Com. Com.
N/C N/C
