Gianni Industries CP-22 Series Specification Sheet

CP-22-GE
CP-22-YL
Statement
The CP-22 series call point, with double pole change over
contacts from N/C to N/O. The main function is to override the
electrical locking/release devices in case of emergency. With
Key to reset unit.

Specifications

Dimensions: 88x88x60 mm
Contact Resistance: 150m
Switch rated: 3A/125V~
No need to power in. It has a double
pole switch for monitoring in case of
emergency when pressed on the
front face of the unit; the contacts
change from N/C to N/O.
Dimension
Unit: mm
(Common Europe Sized)
Reset Key
Copyright © All Rights Reserved. Gianni Industries, Inc. All rights reserved.
DM-CA-CP-21-22 Ver.C Published on 2008.04.29
CP-22-WI
CP-22-RE
Switch 2 Switch 1
6 0
E M E
D O O R G E
R R N C Y
E L E
A S E
8 8
P R
E S
S H
E R
E
8 8
Call Point
(Resettable Switch)
Application
Electromagnetic
locks (locked)
s
l o c k
E M
Electromagnetic
locks (unlocked)
Warranty
The product is warranted against defects in material and
workmanship while used in normal service for a period of 1
year from the date of sale to the original customer. The GEM
policy is one of continual development and improvement;
therefore GEM reserves the right to change specifications
without notice.
GIANNI INDUSTRIES, INC.
No. 13, Zhongxing Rd., Tucheng Dist., New Taipei City 236
, Taiwan (R.O.C.)
Tel: 886-2 2267 7986 / Fax: 886-2 2267 9876
E-Mail: info@gianni.com.tw
Website: gianni.tw
Power supply
Alarm
Power supply
Alarm
