Gianni Industries SWH-040 Specification Sheet

SWH-040
Material: Stainless steel
Momentary (N.O./N.C.) Double Pole Double Throw
Max. Rating : 5A/125/250 VAC
Contact resistance: 50 mΩ Max.(initial)
Operating life(Mechanical) : Over 100,000 times
Operating travel: 2.7 mm
Cables included
SWH-050
Material: Stainless steel
Max. Rating : 5A 125/250 VAC /
Momentary (N.O./N.C.) Double Pole Double Throw
Contact resistance: 50 mΩ Max.(initial)
Operating life(Mechanical) : Over 100,000 times
Operating travel: 2.7 mm
Cables included
SWH-060
Material(Button): Zinc alloy
Max. Rating : 5A 125/250 VA / C
Momentary (N.O./N.C.) Double Pole Double Throw
Contact resistance: 50 mΩ Max.(initial)
Operating life(Mechanical) : Over 100,000 times
Operating travel: 2.7 mm
Cables included
SWH-070
Material: Stainless steel
Momentary (N.O./N.C.) Double Pole Double Throw
Max. Rating : 5A/125/250 VAC
Contact resistance: 50 mΩ Max.(initial)
Operating life(Mechanical) : Over 100,000 times
Operating travel: 2.7 mm
Copyright © 2010 Gianni Industries, Inc. All rights reserved.
DM-CA-PBT-Switch Ver. E Published on 2011.05.10
Micro Switch
Free Position
Operation Position
2.7mm
Free Position
Operation Position
2.7mm
Free Position
Operation Position
2.7mm
Operating travel:
2.7mm
Free Position
Operation Position
Operating travel:
2.7mm
2.7mm
GIANNI INDUSTRIES, INC.
No. 13, Zhongxing Rd., Tucheng Dist., New Taipei
City 236,Taiwan (R.O.C.)
Tel: 886-2 2267 7986 / Fax: 886-2 2267 9876
E-Mail: inquiry@gianni.com.tw
Website: gianni.tw
M30 x P1.5mm
35.8
28.3
30.3
M30 x P1.0mm
35.8
23.0
2.0
38.0
M30 x P1.0mm
35.8
13.0
25.3
27.9
27.9
