2012 NEW PRODUCT RELEASE
HT-S4505
More Reasons to Choose an Onkyo Home Cinema
If the four HDMI
inputs, Audio Return Channel, convenient HDMI-linked set-up display, and Dolby
®
decoding haven't already persuaded you, here are three more reasons to consider the HT-S4505 home cinema. Firstly, Onkyo's acclaimed
WRAT (Wide Range Amplifier Technology)—formerly a feature offered only on its higher-end models—is now included. This noise-
reducing technology contributes to exceptionally good audio performance across a wide dynamic range. Secondly, this model features
Audyssey 2EQ
, which calibrates the speakers and amp to match your room's acoustics, thus perfecting the surround sound; and Audyssey
®
Dynamic Volume
, which lowers the volume of irritating commercials while making movie dialogue easier to hear. Thirdly, the active
®
subwoofer is designed for high output and very low power consumption, rounding out a compact, powerful speaker set. All this (and much
more) adds up to what we think is the best-value, best-performing, best-equipped home cinema package around for the money.
HT-R558
5.1-Channel Home Cinema Receiver
• 100 W/Ch
(6 Ω, 1 kHz, 1% THD, 1 Channel Driven, IEC);
120 W/Ch
(6 Ω, 1 kHz, 1% THD, 1 Channel Driven, JEITA)
• HDMI
®
Support for 3D, Audio Return Channel,
DeepColor
, x.v.Color
, LipSync, Dolby
TrueHD,
™
™
®
DTS-HD Master Audio
, DVD-Audio, Super Audio
™
CD, Multichannel PCM, and CEC
• 4 HDMI Inputs and 1 Output
• Dolby
TrueHD, DTS-HD Master Audio
, Dolby
®
™
Digital Plus, DTS-HD High-Resolution Audio
Decoding
• Direct Digital Connection of iPod/iPhone via
Front-Panel USB Port
• WRAT (Wide Range Amplifier Technology)
• Discrete Output Stage Circuitry
• Overlaid On-Screen Display (OSD) via HDMI
• Audyssey 2EQ
for Room Acoustic Correction
®
• Audyssey Dynamic EQ
for Loudness Correction
®
• Audyssey Dynamic Volume
to Maintain Optimal
®
Listening Level and Dynamic Range
• TI Burr-Brown 192 kHz/24-Bit DACs for All Channels
• PLL (Phase Locked Loop) Jitter-Cleaning Circuit
Technology for S/PDIF Audio
• H.C.P.S. (High Current Power Supply) Massive High
Power Transformer
• Optimum Gain Volume Circuitry
• Advanced 32-Bit Processing DSP Chip
• 4 DSP Modes for Gaming: Rock, Sports, Action,
and RPG
5.1-Channel Home Cinema Receiver/Speaker Package
• Advanced Music Optimizer for Compressed Digital
Music Files
• Theater-Dimensional Virtual Surround Function
• CinemaFILTER
™
• Direct Mode
• Double Bass Function
• Non-Scaling Configuration
• A-Form Listening Mode Memory
• Mass Storage Class USB Memory Playback Capability
• HDTV-Capable (720p/1080i) Component Video
Switching (2 Inputs and 1 Output)
®
• 5 Composite Video Inputs (1 Front/4 Rear) and
™
2 Outputs
• 3 Digital Audio Inputs (2 Optical and 1 Coaxial)
• 6 Analog Audio Inputs (1 Front/5 Rear) and 1 Output
• Speaker A/B Terminals
• Color-Coded Speaker Terminals
• Headphone Jack
• Crossover Adjustment (40/50/60/70/80/90/100/120/
150/200 Hz)
• A/V Sync Control (Up to 400 ms at 48 kHz)
• Tone Control (Bass/Treble) for Front L/R Channels
• 3-Mode Display Dimmer (Normal/Dim/Dimmer)
• 40 FM/AM Random Presets
• RDS (PS/RT/PTY/TP) (European Model Only)
• RIHD (Remote Interactive over HDMI) for System
Control
• Compatible with RI (Remote Interactive) Dock for
iPod/iPhone
• Full-Function RI Remote Control
BLACK
Color availability depends on region.
TrueHD/DTS-HD Master Audio
®
HTP-558
5.1-Channel Home Cinema Speaker System
SKF-558 Full-Range Bass Reflex Front Speakers
• 8 cm Cone
• Max. Input Power: 120 W
• Gloss Finished
• Wall-Mounting Capability
SKC-391 Full-Range Bass Reflex Center Speaker
• 8 cm Cone
• Max. Input Power: 120 W
• Gloss Finished
• Wall-Mounting Capability
SKC-391C Full-Range Acoustic Suspension Center
Speaker (Asian Model)
• 8 cm Cone x 2
• Max. Input Power: 120 W
• Gloss Finished
• Magnetically Shielded
• Wall-Mounting Capability
SKR-558 Full-Range Bass Reflex Surround Speakers
• 8 cm Cone
• Max. Input Power: 120 W
• Gloss Finished
• Wall-Mounting Capability
Note: All speakers feature an impedance of 6 Ω and color-coded speaker
terminals.
SKW-558 Bass Reflex Powered Subwoofer
• 16 cm Cone
• Max. Output Power: 80 W (Minimum Continuous
Power, 4 Ω, 100 Hz, IEC)
• Gloss Finished
• Down-Firing
SILVER
Microphone for
Audyssey
™
