Onkyo HT-S8230(S) Service Manual

SERVICE MANUAL SERVICE MANUAL
5.1-CH HOME THEATER SYSTEM
HT-S8230(S)
MODEL
- - - - - - - - - - - - HTP-8230 (5.1-channel speaker package) - - - - - - - - - - - -
- - - - - HT-R8230 (AV Receiver) - - - - -
Silver model
SMDD
SAFETY-RELATED COMPONENT
WARNING!!
COMPONENTS IDENTIFIED BY MARK
SCHEMATIC DIAGRAM AND IN THE PARTS LIST ARE
CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK.
REPLACE THESE COMPONENTS WITH ONKYO
PARTS WHOSE PART NUMBERS APPEAR AS SHOWN
IN THIS MANUAL.
MAKE LEAKAGE-CURRENT OR RESISTANCE
MEASUREMENTS TO DETERMINE THAT EXPOSED
PARTS ARE ACCEPTABLY INSULATED FROM THE
SUPPLY CIRCUIT BEFORE RETURNING THE
APPLIANCE TO THE CUSTOMER.
120 V AC, 60 Hz
ON THE
HT-S8230
Ref. No. 3816
082004
