Gianni Industries Z-GL600 Bracket Specification Sheet

Application of the Electromagnet:GL600-F
Installation of Z bracket on In-swing Doors
1
Install the electromagnet on
the door frame. Make sure
t h e d o o r m a y b e
opened/closed.
5
Close the door and turn on
the power.
Copyright © Gianni Industries, Inc. All rights reserved.
DM-CA-Z-GL600 Ver. E Published on 2011.09.08
4 8
5
5 5
. 5
2 0
3
2
Assemble Z bracket. Make
sure it is still loose.
6
Power
Let the armature plate and
electromagnet bond together.
Z-GL600 Bracket
n- wing doors
I S
4 0
4 3
2 0
3
4 2
8
4 8
3
Insert the guide pins into the
armature plate.
Finish
Press Z bracket to the door
leaf and fasten it.
GIANNI INDUSTRIES, INC.
No. 13, Zhongxing Rd., Tucheng Dist., New Taipei
City 236,Taiwan (R.O.C.)
Tel: 886-2 2267 7986 / Fax: 886-2 2267 9876
E-Mail: inquiry@gianni.com.tw
Website: gianni.tw
Armature
Plate
Frame
Z-Bracket
In-swing
2 0
3
Unit:mm
4
Fasten the armature plate to
Z bracket. Insert the rubber
washer between them.
