Gianni Industries TB-400 Specification Sheet

Application of Midi, Mini series magnet
Suitable for Shallow Frame or wooden sliding Doors
Mortise Mount Magnet
Frame
Face mount Magnet
Frame
Surface mount Magnet
Frame
Copyright © Gianni Industries, Inc. All rights reserved.
DM-CA-TB-400 Ver. F Published on 2011.09.09
Mortise
magnet
Armature
TB-400
Face mount
magnet
Armature
TB-400
Surface mount
magnet
Armature
TB-400
TB-400 Bracket
3 6
5 3
5
1 6
M 8
Unit:mm
GIANNI INDUSTRIES, INC.
No. 13, Zhongxing Rd., Tucheng Dist., New Taipei
City 236,Taiwan (R.O.C.)
Tel: 886-2 2267 7986 / Fax: 886-2 2267 9876
E-Mail: inquiry@gianni.com.tw
Website: gianni.tw
0
1 9
