Gianni Industries Z-150 Installation Manual

Application of Electromagnet:10003F
Installation of Z bracket on In-swing Doors
1
Install the electromagnet on
the door frame. Make sure
t h e d o o r m a y b e
opened/closed.
5
Close the door and turn on
the power.
Copyright © Gianni Industries, Inc. All rights reserved.
DM-CA-Z-150 Ver. E Published on 2011.09.08
3 0
6
4 0
1 8
0
2
Assemble Z bracket. Make
sure it is still loose.
6
Power
Let the armature plate and
electromagnet bond together.
Z-150 Bracket In-swing doors
1 8
0
4 8
6
3 8
3
Insert the guide pins into the
armature plate.
Finish
Press Z bracket to the door
leaf and fasten it.
GIANNI INDUSTRIES, INC.
No. 13, Zhongxing Rd., Tucheng Dist., New Taipei
City 236,Taiwan (R.O.C.)
Tel: 886-2 2267 7986 / Fax: 886-2 2267 9876
E-Mail: inquiry@gianni.com.tw
Website: gianni.tw
Armature
Plate
Frame
Z-Bracket
In-swing
2 4
1 7
0
3 2
4
Fasten the armature plate to
Z bracket. Insert the rubber
washer between them.
Unit:mm
