Gianni Industries UBK-010 Specification Sheet

UBK-013
UBK-013 contains a spacer for adjustment according
to door thickness.
UBK-013 For 10~12mm thickness of glass door
Frame
U-Bracket
Outswing
1 6
UBK-013
spacer included
Copyright Gianni industries, inc. All rights reserved.
DM-CA-UBK-013 Ver. D Published on 2008.07.29
Armature
Rubber Washer
Spacer
Frameless glass door
1 9
0
5
4 5
1 3
2 3
UBK-013 Bracket
For full franeless glass doors
