INSTALLATION INSTRUCTIONS
Acrylux Builder Series Whirlpools
Model 6030Y2A.118.XXX
Model 6030Y2A.218.XXX
Thank you for selecting American Standard – the benchmark of fine quality for over 100 years. To ensure this product is installed properly, please
read these instructions carefully before you begin. Local building codes vary by location. Observe all local plumbing and building codes.
RECOMMENDED TOOLS AND MATERIALS
Tape Measure
Safety Glasses
IMPORTANT:
• Read installation instructions carefully before starting project.
• Before you begin, locate appropriate product reference (below).
• Allow tub to reach room temperature before installation.
• Water test tub before installation.
• Keep instructions for warranty information.
6030Y2A.118.XXX
6030Y2A.218.XXX
1"
25mm
18"
457mm
30"
762mm
6030Y1.118.XXX
6030Y1.218.XXX
59-7/8"
1521mm
STUD LAYOUT:
The American
Standard Acrylux
31-1/2"
Whirlpool will fit all
800mm
standard 30" x 60"
tub walls.
= stud location
P r o d u c t n a m e s l i s t e d h e r e i n a r e t r a d e m a r k s o f A S A m e r i c a , I n c .
© A S A m e r i c a , I n c . 2 0 0 8
Model 6030Y1.118.XXX
Model 6030Y1.218.XXX
Mortar Compound (optional)
Screws, 1" Flathead, Stainless
Motor / Pump
59-7/8"
Access Cover
1521mm
30"
762mm
Motor / Pump
Access Cover
14"
10"
356mm
254mm
6"
GFI Electrical
152mm
Outlet
Drain C L
8"
203mm
Floor Cut Out 6" x 10"
(152 x 254mm)
60"
1524mm
Left-hand drain shown - reverse layout for right-hand drain.
Subject to manufacturing tolerance of [+] or [-] 1/8"
Model 6032Y1.118.XXX
Model 6032Y1.218.XXX
19"
483mm
6032Y1.118.XXX
6032Y1.218.XXX
15"
381mm
STUD LAYOUT:
The American
Standard Acrylux
Whirlpool will fit all
standard 32" x 60"
tub walls.
= stud location
Pencil
Drill
STUD LAYOUT:
The American Standard Acrylux Bathtub
will fit all standard 30" x 60" tub walls.
14"
10"
356mm
254mm
6"
31-1/2"
152mm
800mm
Drain C L
8"
203mm
Floor Cut Out 6" x 10"
(152 x 254mm)
60"
1524mm
= stud location
59-7/8"
1521mm
15"
12"
381mm
305mm
6"
33-1/2"
152mm
851mm
Drain C L
8"
203mm
Floor Cut Out 6" x 12"
(152 x 305mm)
1524mm
Saber Saw
Level
GFI Electrical
Outlet
32"
813mm
18"
457mm
Motor / Pump
Access Cover
GFI Electrical
Outlet
60"
7542 8 2- 1 00 Re v. A
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for American Standard Acrylux Builder Series Whirlpools 6030Y1.118.XXX
Summary of Contents for American Standard Acrylux Builder Series Whirlpools 6030Y1.118.XXX
-
Page 1: Installation Instructions
Model 6030Y2A.218.XXX Thank you for selecting American Standard – the benchmark of fine quality for over 100 years. To ensure this product is installed properly, please read these instructions carefully before you begin. Local building codes vary by location. Observe all local plumbing and building codes. - Page 2 • Fill tub with water, make sure water is above jets. Run for 10 minutes. Inspect all fittings, plugs and connections for possible leaks. • Drain tub. If any leaks are found, call American Standard Customer Service Department at 1-800-442-1902.
- Page 3 CLEANING • Normal cleaning: wash with warm water, soft cloth and a mild liquid detergent. ® • Ideal cleaners are Soft Scrub Gel or Comet Gel • Do not use any abrasive cleaners or metal scrapers. • FLUSHING INSTRUCTIONS: Whirlpool unit must be flushed every ninety (90) days with a sanitizing chemical such as a spa freshener, algicide or household bleach.
- Page 4 AS AMERICA, INC. (“AMERICAN STANDARD”) LIMITED WARRANTY FOR ACRYLUX PRODUCTS AS America, Inc. (“American Standard”) warrants to the original consumer purchaser that it will, at its option, repair or replace any of its plumbing products found by it to be defective under normal use and maintenance within the following periods from date of purchase: Electronic Components - two (2) years;...
