OVERVOLTAGE CATEGORY III
This meter meets the IEC 610-1-2001 standard for OVERVOLTAGE CATEGORY III. Cat III
meters are protected against overvoltage transients in fixed installation at the distribution
level. Examples include switches in the fixed installation and some equipment for industrial
use with permanent connection to the fixed installation.
SAFETY INSTRUCTIONS
This meter has been designed for safe use, but must be operated with caution. The rules
listed below must be carefully followed for safe operation.
1.
NEVER apply voltage or current to the meter that exceeds the specified maximum:
Function
V DC or V AC
mA AC/DC
A AC/DC
Frequency, Resistance, Capacitance,
Duty Cycle, Diode Test, Continuity
Temperature
2.
USE EXTREME CAUTION when working with high voltages.
3.
DO NOT measure voltage if the voltage on the "COM" input jack exceeds 600V above
earth ground.
4.
NEVER connect the meter leads across a voltage source while the function switch is in
the current, resistance, or diode mode. Doing so can damage the meter.
5.
ALWAYS discharge filter capacitors in power supplies and disconnect the power when
making resistance or diode tests.
6.
ALWAYS turn off the power and disconnect the test leads before opening the covers to
replace the fuse or battery.
7.
NEVER operate the meter unless the back cover and the battery and fuse covers are in
place and fastened securely.
Input Protection Limits
Maximum Input
1000V DC/750V AC, 200Vrms on 400mV range
500mA 250V fast acting fuse
20A 250V fast acting fuse(30 seconds max every
15 minutes)
250Vrms for 15sec max
60V DC/24V AC
4
EX420-EU_ENG
V3.1
6/09
