Quick reference to display

Low-battery warning (see page 8)
System status
• Cool : Cooling is activated. *
• Heat : Heating is activated. *
• Stg2: Auxiliary heat is activated. **
* If Heat or Cool
** Applies to P310-0210 model only.
Setpoint indicator
Appears when the setpoint
temperature is displayed.
is flashing, compressor protection is engaged (see page 7).
Totaline Basic 1H/1C & 2H/1C
Temperature display
The ambient (measured)
temperature is normally
displayed. To view the
setpoint temperature, press
either of the temperature
adjustment buttons once.
The setpoint temperature
will appear for five seconds.
3
