The Parts

Unpacking and identifying parts
Remove the parts one at a time from the box. Make a check in the space provided as you identify each
part. Any part that is packed in an envelope should be identified and then kept in that envelope until
it's called for. Do not throw away any packing material until all parts are accounted for. If anything is
missing, please contact Tiffen for a replacement.
You should have:
Steadicam Merlin
DVD
: "The Art of Steadicam Merlin"
Nine threaded stainless-steel weights
One Start and two Finish weights (shipped installed on Merlin)
Six Mid weights
Plastic Bag, containing:
Mounting Screw
One
Locating Pin
One
"Gezornenplatz" Screw
One
and support for some heavy camcorders)
Tripod Adaptor Plate
When all parts have been located and identified, watch
Section 3 of the DVD,
Then continue with the Manual.
, including 3 pre-installed weights and dovetail plate
(with cushioning rubber O-rings installed):
for mounting camcorder to Merlin
set: pin and attaching screw
(provides optional stiffening
Unfolding the Merlin.
