GEM 962 EZ-Plus Specifications

2-door access control system

Advertisement

Quick Links

Features
Simple and quick programming using a Master
tag.
The first Tag presented to the system will be
stored in the memory as Master Tag.
Programming functions:
Add Tags
Delete Tags
Clear Memory
(Secure Tag Reader)
Adjust/Set Relay operating time
Lost Tags can be deleted using an optional tag
simulator in conjunction with the master tag.
Controller supports two readers
Controller can control 2 independent doors or a
single door (jumper setting)
Controller holds up to 2000 tags in non-volatile
memory
Each reader can have its own set of tags or can
be set to add tags automatically to both
readers.
The last 2000 transactions stored with date &
time stamp in non-volatile memory (only valid
transactions)
S i m p l e l o g g i n g s o f t w a r e t o d o w n l o a d
transaction data and set date & time
Optional Door Switch will reset door strike relay
when the door opens
Door Reed Switch Input for Anti-Trailing
Simple installation (3 or 5 wires from reader to
controller)
Easy Programming
(Master Tag)
ADD state
(Once)
GREEN lamp to start flashing (short)
Delete Tags
(Twice)
GREEN lamp to start flashing (double short)
Time Adjust and Toggle Mode Selection
(Three times)
GREEN lamp to start flashing (long)
GIANNI INDUSTRIES, INC.
No. 13, Zhong Sing Road, Tu-Cheng Industrial Zone,
Tu-Cheng City, Taipei, Taiwan 23678
Tel: 886-2 2267 7986 / Fax: 886-2 2267 9876
E-Mail: info@gianni.com.tw
Website: gianni.tw
Copyright 2008 Gianni industries, inc. All rights reserved.
DM-CA-962 EZ-Plus Ver. A Published on 2008.07.22
962 EZ-Plus
2-Door Access Control System
Statement
The system consists of a controller with relays to
operate a single door or two independent doors.
The controller supports two various
Reader
or two Wiegand devices which can be
mounted up to 50 meters from the controller. The
Readers are fully potted and suitable for mounting
outdoors. Tampering with these readers will not
compromise the systems security.
Programming the system is very simple and
requires a Master Tag to put the unit into
programming mode and then to follow a simple
procedure to add or delete cards.
A jumper setting allows tags to be added
automatically to both readers or to allow each
reader to have its own set of tags.
714-60
Mifare UID
Reader (In 26-bit wiegand mode)
656-10
125 KHz Secure Tag Reader
684-10
125 KHz OEM Reader (In 26-bit wiegand mode)
The products are manufactured under an ISO
9 0 0 1
Management Program environment back its
product quality, performance and commitment
to customer satisfaction.
Secure Tag
962
Controller
&
Q C 0 8 0 0 0 0 C e r t i f i e d Q u a l i t y
