GEM E-ACCESS E1196 Instructions

GEM E-ACCESS E1196 Instructions

Bluetooth access control reader

Advertisement

Quick Links

Getting Started
With
E E
-Access Applications
®
E1196
App
Instructions
E-Access E1196 App Instructions:
1
Introduction of App's Main Page
Profile:
Enter a Master / User name for this
phone only at the first time.
Setting:
Device
E-Access Device Settings Page.
Device:
E-Access Device Name.
Auto:
(Automatic Access for Handsfree):
Turn ON/OFF for the Automatic
Automatic
Access Handsfree function.
Profile
Access
Setting
Bi-stable Relay:
When you select to enable Bi-stable
function, you can press down the E
button for few seconds to activate and
keeps the door unlocked indefinitely.
To return nornal operation, press the E
button again.
2
3
Click on the device name (e.g.E1196
as shown) and pull down all the
available E-Access devices around
you.
You can select a device from the
list as shown, or you can press
"Auto" in the list so that E-Access
will operate with the closest
E-Access device around you.
3
Enter personal name.
4
Master / User Logon E-Access:
Select an E-Access device from the
E-Access List and enter the password
given by the Master.
Logon Notes:
1. The Master / User must enter a
correct Password to logon.
2. How to Reset/Change the Master
account:
(1) Restart the power of E-Access
device, and then enter the
password 12345 (default) within
30 seconds.
(2) Next, click on the "Register"
button to register, then return to
the first page, and you then
become the Master.
5
Master / User Logon E-Access:
Select an E-Access device from the
E-Access List and enter the password
given by the Master.
Logon Notes:
1. The Master / User must enter a
correct Password to logon.
2. How to Reset/Change the Master
account:
(1) Restart the power of E-Access
device, and then enter the
password 12345 (default) within
30 seconds.
(2) Next, click on the "Register"
button to register, then return to
the first page, and you then
become the Master.
Master Setting Page:
Register:
6
You must click on Register button to
complete registration before opening
the door by your phone.
User List:
Only the Master can view/enable/delete
all the Users and view User passwords.
Settings:
E-Access settings include Proximity
Read Range, Device Name, Relock
Time, and Delete all Users.
Backup:
Backup all Users data from the device.
Restore:
Restore the last backup data.
7
User List:
All authorized Users can be
viewed on the User List.
Click on
User.
8
9
10
Scan the QR-code to download E-Access E1196 App
or Search "E-Access E1196" to download.
to add a new
Scan the QR-code to download E1196 Instructions.
Add New User:
Add User Name:
The Master enters a User name.
Password:
The Master assigns a password for the new User
to register on E-Access system.
The new user will be shown on the User list.
Master can slide from right to
left so a User can be Enabled
/Disabled/Deleted by the Master.
Enable:
Enable a User account.
Disable:
Disable a User account.
Delete:
Delete a User account.
Settings Page
E-Access Name:
Edit the E-Access name.
Relock Time (sec):
Set the time for relock time.
Enable/Disable All Users:
Enable or disable all User accounts
except the Master.
Delete All Users:
Delete all User accounts except
the Master.
Proximity Read Range
(from 0 to 50 meters):
Set proximity read range for
hands-free automatic access.
http://www.gianni.com.tw/pdf/guide/E1196.pdf
