IC-3116W
Quick Installation Guide (English)
11-2013 / v1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IC-3116W and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Edimax IC-3116W

Summary of Contents for Edimax IC-3116W

  • Page 1 IC-3116W Quick Installation Guide (English) 11-2013 / v1.0...
  • Page 2 (www.gnu.org) and LPGL(www.gnu.org) Websites to view the terms of each license. The GPL Code and LGPL Code used in Edimax products are distributed without any warranty and are subject to the copyrights of their authors. For details, see the GPL Code and LGPL Code licenses. You can download the firmware-files at http://www.edimax.com...

  • Page 3: Table Of Contents

    I. Product Information ................4 I-1. Package Contents ................4 I-2. Back Panel ..................4 I-3. LED Status ..................5 I-4. Product Label ................... 6 I-5. Reset ....................6 II. Hardware Installation ................7 III. Camera Setup ..................8 III-1. Installing & Using EdiView Finder ............. 8 III-1-1.

  • Page 4: Product Information

    I. Product Information I-1. Package Contents IC-3116W CD-ROM Power Adapter Ethernet Cable Mounting Kit I-2. Back Panel MAC/Cloud ID WPS/Reset Button LAN Port 12V DC Power Port...

  • Page 5: Led Status

    I-3. LED Status LED Color LED Status Description Network camera is on and connected to cloud server. Quick Flashing Network camera is restarting. Power Green Network camera is starting up OR Slow Flashing (1 x network camera is not connected per second) to cloud server.

  • Page 6: Product Label

    I-4. Product Label The product label located on the back of the camera displays the MAC address and cloud ID of your network camera. The MAC address and cloud ID are the same for easy reference. The cloud ID allows you to view a live stream from your network camera remotely (from any Internet connection) as described later in III-4.

  • Page 7: Hardware Installation

    II. Hardware Installation Follow the instructions below to ensure your camera is properly connected and ready for setup. Use an Ethernet cable to connect the network camera’s LAN port to a router/switch/access point’s LAN port, as shown below. Connect the power adapter to the network camera’s power port and to a power supply, as shown below.

  • Page 8: Camera Setup

    III. Camera Setup Your network camera can be up and running in just a few minutes. First, please follow the instructions below for Windows or Mac in III-1. Installing & Using EdiView Finder to install the EdiView Finder software and connect your camera to your wireless network.
  • Page 9 Click “Next” and follow the on-screen instructions to install the EdiView Finder software utility. When installation is complete, select “Launch EdiView Finder Utility” before clicking “Finish”. Or double click the ”EdiView Finder Utility” icon on your desktop to launch EdiView Finder. EdiView Finder will list all cameras on your local network, along with each camera’s name, model, IP address and MAC address.
  • Page 10 Double click your camera and then choose “Yes” or “No” if you wish to set up a wireless connection. If you choose “No” please go to step 10. The IC-3116W is a wireless camera, please choose “Yes” to set up your wireless connection.
  • Page 11 Select your wireless network from the list and enter the correct password in the “Password” field, before clicking “OK”. This is the wireless network which your camera will connect to. Unplug the Ethernet cable from your network camera and click “Next”. Please wait a moment for the camera to detect the connection.
  • Page 12 When the connection is detected as shown below, please click “Next”. Enter a name and password for your camera. The password will be used later to log in to your camera remotely via its cloud ID, web interface or via the EdiView smartphone app. Click “OK” to continue.

  • Page 13: Iii-1-2. Mac

    Insert the included CD into your CD-ROM drive and browse to the “Mac” folder. Copy the “EdiView Finder” file to your desktop and double click the icon to open EdiView Finder. EdiView Finder is also available for download from the Edimax website: http://www.edimax.com/EdiViewFinder.htm...
  • Page 14 EdiView Finder will list all cameras on your local network, along with each camera’s name, model, IP address and MAC address. Click the search icon to refresh the list if your camera is not displayed. The network camera’s IP address is displayed on this screen. After setup, you can enter this IP address into the URL bar of a web browser on the same local network to access your network camera’s web-based configuration interface.
  • Page 15 Enter a name and password for your camera. The password will be used later to log in to your camera remotely via its cloud ID, web interface or via the EdiView smartphone app. Click “Next” to continue. The next screen will indicate that setup is complete. The camera is operational and ready to be configured for a wireless connection.

  • Page 16: Iii-2. Wps (Wi-Fi Protected Setup)

    III-2. WPS (Wi-Fi Protected Setup) The WPS button is a quick and easy method to establish a secure wireless connection between your network camera and your wireless router/access point. Press and hold the WPS button on your wireless router/access point for the correct length of time to activate its WPS.

  • Page 17: Iii-3. Web-Based Management Interface

    III-3. Web-Based Management Interface When you are using the same local network as your camera, you can use the web-based management interface to view or configure the camera. You can access the web-based management interface with a web browser on a smartphone or computer.
  • Page 18 You may be prompted to allow a Java add-on to run. Please click the message where it says “click here” and then click “Run Add-on”. If any other security warnings/prompts appear, please select “Run” or “Allow” or similar, depending on your browser. Enter the username and password for your network camera (default username: admin default password: 1234).

  • Page 19: Iii-3-1. Wireless Settings

    Refer to the user manual for more information about using the web-based configuration interface. Mac users please continue to III-3-1. Wireless Settings to set up your camera’s wireless connection. III-3-1. Wireless Settings The “Wireless” page of the web-based management interface allows you to configure the network camera’s wireless connection.

  • Page 21: Iii-3-1-2. Computer

    Wireless Connection Select “Enable” to enable the wireless connection. Click “Refresh” to display all available Wi-Fi Available Network (1) networks. Select your Wi-Fi network from the list. This is the Available Network (2) wireless network which your camera will connect to. WPA Pre Shared Key Enter your Wi-Fi password.
  • Page 22 Configure the wireless settings A – E shown in the table below: Wireless Connection Select “Enable” to enable the wireless connection. Click “Refresh” to display all available Wi-Fi Available Network networks. Select your Wi-Fi network from the list. This is the Connected wireless network which your camera will connect to.

  • Page 23: Iii-4. Myedimax.com

    III-4. Myedimax.com You can use your network camera’s Myedimax.com cloud ID to monitor your camera remotely using a web browser from any Internet connection. The network camera’s green power LED must display on for this function to work. Identify your network camera’s cloud ID. The cloud ID is displayed in EdiView Finder (see III-1.) and on the product label on the back of the network camera (see I-4.).
  • Page 24 If any other security warnings/prompts appear, please select “Run” or “Allow” or similar, depending on your browser. Enter your camera’s password (default password: 1234) and click “OK” to see a live stream from your network camera.

  • Page 25: Iii-5. Ediview App

    III-5. EdiView App You can use the free EdiView smartphone app to monitor your camera remotely using a smartphone from any Internet connection. The network camera’s green LED must display on for this function to work. Search the Apple app store or Google Play for “EdiView”. Download and install the EdiView app.
  • Page 26 Select your network camera, enter the password when prompted (default password is 1234) and tap “OK”. iOS:...
  • Page 27 Android: Android users select the camera name and tap “Done”. iOS users tap “Live” from the menu across the bottom of the screen.
  • Page 28 Android: iOS: For more detailed guidance on using the EdiView app, please refer to the user manual.
  • Page 29 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 30 EU Declaration of Conformity English: This equipment is in compliance with the essential requirements and other relevant provisions of Directive 2004/108/EC, 2006/95/EC, 2009/125/EC. French: Cet équipement est conforme aux exigences essentielles et autres dispositions de la directive 2004/108/EC, 2006/95/EC, 2009/125/EC Czechian: Toto zařízení...

  • Page 31: Declaration Of Conformity

    Declaration of Conformity We, Edimax Technology Co., Ltd., declare under our sole responsibility, that the equipment described below complies with the requirements of the European R&TTE directive (1999/5/EC, 2006/95/EC) Equipment: 720p Wireless H.264 Day & Night Network Camera Model No.: IC-3116W...
  • Page 32 Notice According to GNU General Public License Version 2 This product includes software that is subject to the GNU General Public License version 2. The program is free software and distributed without any warranty of the author. We offer, valid for at least three years, to give you, for a charge no more than the costs of physically performing source distribution, a complete machine-readable copy of the corresponding source code.
  • Page 33 1. You may copy and distribute verbatim copies of the Program’s source code as you receive it, in any medium, provided that you conspicuously and appropriately publish on each copy an appropriate copyright notice and disclaimer of warranty; keep intact all the notices that refer to this License and to the absence of any warranty; and give any other recipients of the Program a copy of this License along with the Program.
  • Page 34 5. You are not required to accept this License, since you have not signed it. However, nothing else grants you permission to modify or distribute the Program or its derivative works. These actions are prohibited by law if you do not accept this License. Therefore, by modifying or distributing the Program (or any work based on the Program), you indicate your acceptance of this License to do so, and all its terms and conditions for copying, distributing or modifying the Program or works based on it.
