INSTRUCTION BOOKLET
COOKER HOOD
ZHC945

Advertisement

Table of Contents
loading

Related Manuals for Zanussi ZHC945

Summary of Contents for Zanussi ZHC945

  • Page 1 INSTRUCTION BOOKLET COOKER HOOD ZHC945...

  • Page 3: For The Installer

    If you require guidance in the use of the appliance or require further information on Zanussi Products, please contact our Customer Care Department. For general enquiries concerning your Zanussi appliance or for further information, visit our website at http://www.zanussi.co.uk...

  • Page 4: Important Safety Information

    Refer to your local Zanussi Ser- • If the room where the hood is to be used contains vice Force Centre. Always insist on genuine spare a fuel burning appliance such as a central heating parts.

  • Page 5: Your Appliance

    YOUR APPLIANCE...

  • Page 6: Control Panel

    OPERATING INSTRUCTIONS The cooker hood is designed to extract unpleasant odours from the kitchen, it will not extract steam. The appliance can be installed to recirculate or extract contaminated air. Control Panel The hood can be switched on pushing directly onto the requested speed without fi rstly having to select 0/1 button.
  • Page 7 To Operate Select the required fan speed and light if required. Recirculation In the recirculation mode the contaminated air enters the cooker hood through the grease fi lters. The air is cleaned by passing through the charcoal fi lters before being passed back into the kitchen through the grilles in either side of the chimney stack.

  • Page 8: Maintenance And Cleaning

    MAINTENANCE AND CLEANING Before carrying out any maintenance or clea- ning isolate the cooker hood from the mains supply. The cooker hood must be kept clean, as a build up of grease or fat can be a fi re hazard. External Cleaning Wipe the cooker hood frequently with warm soapy water using a mild detergent.

  • Page 9: Charcoal Filters

    MAINTENANCE AND CLEANING Before carrying out any maintenance or cleaning isolate the cooker hood from the mains supply. Charcoal Filters In the recirculation mode the charcoal fi lters absorb smells and unwanted odours. Enabling the alarm signal • In Recirculation version Hoods, the Filter saturation alarm can be enabled on installation or at a later date. •...

  • Page 10: Something Not Working

    SERVICE AND SPARE PARTS If you require an engineer or spare parts For general assistance with your appliance or contact your local Service Force Centre by for further information on Zanussi products telephoning: please contact our Customer Care Department. Customer Care Department...

  • Page 11: Guarantee Conditions

    GUARANTEE CONDITIONS We Zanussi, undertake that if within 12 months of the date of the purchase this Zanussi built-in appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, the company will, at our option repair or replace the same FREE OF ANY CHARGE for labour, materials or carriage on condition that: •...

  • Page 12: Installation Instructions

    INSTALLATION INSTRUCTIONS It is dangerous to alter the specifi cations or attempt to modify this product in any way. Technical Information DIMENSIONS HEIGHT OF CANOPY: 64 mm HEIGHT OF CHIMNEY: (UPPER SECTION) 470 mm (LOWER SECTION) 745 mm WIDTH OF CANOPY : 898 mm DEPTH OF CANOPY: 520 mm...

  • Page 13: Installing The Cooker Hood

    INSTALLING THE COOKER HOOD Please ensure that when the appliance is installed it is easily accessible to an engineer in the event of a breakdown. All installations must comply with the local authorities requirements for the discharge of exhaust air. Incorrect installation may affect the safety of this cooker hood.
  • Page 14 INSTALLING THE COOKER HOOD Clearance Height The cooker hood is designed to be fi tted over a cooking appliance at the clearance heights stated, providing the maximum output of the appliance beneath does not exceed the maximums quoted in the Technical Speci- fi...

  • Page 15: Fitting The Wall Brackets

    INSTALLING THE COOKER HOOD Fitting the Wall Brackets Wall marking: • Draw a vertical line on the supporting wall up to the ceiling, or as high as practical, at the centre of the area in which the hood will be installed. •...

  • Page 16: Mounting The Hood Body

    INSTALLING THE COOKER HOOD Mounting the hood body • Before attaching the hood body, tighten the two screws Vr located on the hood body mounting points. • Hook the hood body onto the screws 12a • Fully tighten support screws 12a •...
  • Page 17 INSTALLING THE COOKER HOOD Upper exhaust fl ue • Slightly widen the two sides of the upper fl ue and hook them behind the brackets 7.2.1, making sure that they are well seated. • Secure the sides to the brackets using the 4 screws 12c (2,9 x 9,5) supplied.
  • Page 20 436002548_03 - 070319 © Electrolux plc 2002...
