1

BEFORE USING THE APPLIANCE

1.1

SAFETY INSTRUCTIONS

Norms and regulations to be respected
• The dishwasher may only be used to clean household dishes. If the appliance is used for other
purposes or in a wrong manner, the manufacturer declines all responsibilities for possible damages.
• For safety reasons, no modifications must be carried out on the appliance.
• Before connecting the appliance to the electric power supply system, check that the power supply at
the place of installation is compatible with the electric data indicated on the data tag.
• The installation must be carried out by qualified personnel.
Before running the appliance for the first time
• Make sure the dishwasher was not damaged during transport. Do not hook up the appliance if there
is any damage. In case of damage, contact the vendor.
For the safety of children
• Do not allow children to play with the appliance.
• Detergents can cause permanent damage to eyes, mouth and throat.
They should therefore be kept outside the reach of children.
• The water in the dishwasher is not drinkable. Any residues of detergent in the appliance constitute a
source of danger for children. They must therefore be kept away from the open dishwasher.

Daily use

• Do not turn on the dishwasher if the electric cable, or the water supply or water drainage pipes are
damaged, or if the control board, the work surface or the base are in very bad condition.
• In case of a malfunction, shut off the water supply, then turn off the appliance and pull the electric
plug from the outlet. If there is a permanent electric connection, turn off the service switch (if present)
or remove the fuse (or fuses).
• To remove the plug from the electric outlet, hold the plug itself and pull; never pull the cable.
• All repairs of the dishwasher must be carried out by specialised personnel. Inappropriate repairs can
create a severe danger for the user. For repairs, you should therefore contact our technical customer
assistance service or a specialised vendor.
• The replacement of the supply cable must be carried out only by the technical service staff.
• If the pipes and tubes are deteriorated, substitute them with new original parts before hooking up
the appliance.
• Do not use detergent substances that could lead to an explosion.
• Do not sit or lean on the open door. The appliance might otherwise tilt over.
• Before adding special dishwasher salt, detergent and rinse aid, make sure that the manufacturer of
these substances recommends their use for household dishwashers.
• Always shut off the water supply when the dishwasher is not in use for longer periods of time, e.g.,
during your vacations.
1 2 3 4 5 6 7 8 9 0 1
1
1 2 3 4 5 6 7 8 9 0 1
1 2 3 4 5 6 7 8 9 0 1
GB
1 2 3 4 5 6 7 8 9 0 1
1 2 3 4 5 6 7 8 9 0 1
1 2 3 4 5 6 7 8 9 0 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Dishwasher and is the answer not in the manual?

Questions and answers

MR SEAN HINTON
June 1, 2025

Ed error code

1 comments:
Mr. Anderson
June 1, 2025

The ED error code on a DeLonghi DEDW6015S dishwasher indicates a communication breakdown between the main PCB (printed circuit board) and the display PCB.

This answer is automatically generated

Summary of Contents for DeLonghi Dishwasher

  • Page 1: Before Using The Appliance

    They must therefore be kept away from the open dishwasher. Daily use • Do not turn on the dishwasher if the electric cable, or the water supply or water drainage pipes are damaged, or if the control board, the work surface or the base are in very bad condition.
  • Page 2: Unpacking - Disposal

    • Always choose a programme that is adequate for the kind of dishes you want to wash and that corresponds to how dirty they are • You should avoid to use too much detergent, dishwasher salt, and rinse aid. Refer to the dosages recommended in the usage instructions provided by the manufacturers of these substances.
  • Page 3: Description Of The Appliance

    DESCRIPTION OF THE APPLIANCE GENERAL PARTS salt container rinse aid container container for detergent data tag filters lower spray-rotor upper spray-rotor electric cable water supply tube 10) water drainage tube 11) lower basket 12) upper basket 13) cutlery container 14) hook for door closing mechanism TECHNICAL DATA capacity (standard settings): 12 Attention: the necessary characteristics...
  • Page 4: Installation

    In order to obtain a perfect seal adjust the door locking device but only after having levelled the machine in its final installation position. WATER CONNECTION The water supply tube C, which accompanies the dishwasher, makes it possible to connect the appliance to a faucet with a _” attachment. During the installation, the following instructions must be followed: •...
  • Page 5: Electric Connections

    During the assembly, the following precautions should be taken: - the drainage tube must not be bent to avoid blockages; - the tube’s end, relative to the top surface of the dishwasher (fig. 4), must be placed at a height between 32 and 80 cm;...
  • Page 6 – always at the beginning of a cycle. Use only special dishwasher salt. Other types of salt (e.g., regular household salt) often contain substances that do not dissolve completely in water and can therefore obstruct the water softener, thus making it unusable.
  • Page 7: Refilling Of Rinse Aid

    The green mark under the cap indicates that there is still enough salt in the container. If the green mark is no longer visible, the salt container needs to be refilled with special dishwasher salt. Refilling of rinse aid The rinse aid, which is released automatically...
  • Page 8: Adding The Detergent

    31 wash cycles. Adding the detergent IMPORTANT! Do not use detergents in this dishwasher that are made for dish washing by hand! These substances produce large quantities of foam but they do not clean the dishes in a dishwasher. They can even lead to a malfunctioning of the appliance.
  • Page 9 How to load and unload the dishwasher There are two dish baskets that allow you to store all different kinds of dishes. • Remove from the dishes any larger pieces of food to avoid an obstruction of the filter and the development of bad odours.
  • Page 10 An optimal arrangement of dishes inside the dishwasher will guarantee best washing results, allowing the appliance will be able to develop its full effectiveness.
  • Page 11 After the cycle is over, the dishes do not need to be dried by hand- they are being dried automati- cally. The dishes can now be taken out or can stay inside the dishwasher until they are needed. • Drying at the end of the cycle is carried out with cold water and there is a 15’ lapse of time.
  • Page 12 Table of wash programmes BUTTONS DETERGENT Dishes Programme descriptions: degree of dirt: Pre-wash pans and dishes until the next Short cold wash to prevent food residues from drying up and forming crusts on the dishes wash cycle 1 warm Pre-wash – Main wash Heavy wash 2 rinse (1 cold –...
  • Page 13: Maintenance

    Clean all these components under running water. It is important to clean all filters thoroughly because the dishwasher cannot function properly with obstructed filters. We recommend to put the cleaned filters back in their positions immediately to avoid damage to the wash pump.
  • Page 14: What To Do In Case Of Malfunctions

    - Are the dishwasher’s baskets overloaded? - Are the spray-rotors blocked by a dish or some cutlery? - Are all filters at the bottom of the dishwasher clean? Are they all in their correct position? - Did you add the correct amount of detergent?
